American Ceiling DWG Section for AutoCAD

American Ceiling DWG Section for AutoCAD

American ceiling – Technical specifications – Sections

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

detail, encounter with direct lining, transverse seal: chamfered edge, separation between battens, sep. between fixations, separation between teachers omega, approx., legend, of the battens, fixing points, wooden battens, omega teacher, fixation for wood, knauf plate, tn screws for, mm plate., uniflott, dilatation band, mineral fiber, vertical section, roof weight:, the structure, Forged direct fixation, longitudinal joint: cc edges, the omega teacher is fixed directly, tn for, fixation knauf, horizontal section

Raw text data extracted from CAD file:

4 Detalle D 151 E 5 7 6 5 8 9 1 A-1 Encuentro con Trasdosado Directo B-1 Junta Transversal: Canto Biselado < 100 2 3 7 A1 A1 B1 B1 C1 C1 2 1 3 850 650 650 650 Separacion entre rastreles Sep. entre fijaciones 500 500 500 Separacion entre maestras omega Aprox. 100 ó 1.0 mm 1 LEYENDA de los rastreles Puntos de fijacion Rastreles de madera 2 Maestra omega 3 Fijacion para madera 4 Placa Knauf 5 Tornillos TN 3,5x25 para placa de 15 mm. o 6 Uniflott 7 Banda de dilatacion 8 Fibra mineral 9 Seccion Vertical E 1:5 Peso del techo: ó 0,30 kN/m2 (Incluida la estructura metalica) D-1 Fijacion Directa a Forjado 5 10 7 6 C-1 Junta Longitudinal: Bordes CC La maestra Omega se fija directamente TN 3,5x35 para esp.>15 10 Fijacion Knauf Seccion Horizontal E 1:5

Language	Spanish
Drawing Type	Section
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials	Wood
Measurement Units
Footprint Area
Building Features
Tags	abgehängten decken, american, autocad, ceiling, DWG, plafonds suspendus, section, sections, specifications, suspenden ceilings, technical
