Arabic Quranic Verse Steel Plate Cutting Pattern Template

This technical drawing depicts a precise cutting template for CNC fabrication of an Arabic calligraphic verse from the Quran designed for steel plate manufacturing. The template spans approximately 1525mm in width and 417mm in height, featuring intricate curved contours formed by 208 arcs and 108 polylines that define the elegant Arabic script. The pattern utilizes negative space cutting, where the calligraphy outlines would be precision-cut from a steel plate using plasma or laser cutting technology. The design incorporates characteristic features of traditional Arabic calligraphy with flowing curves and distinctive letterforms while maintaining structural integrity for fabrication. The cutting paths maintain minimum thickness requirements of approximately 3-5mm between adjacent curves to ensure material stability after cutting. This template is optimized for steel plate fabrication as indicated by the dedicated layer naming convention, making it suitable for architectural features, decorative panels, or religious installations.
