Basement Waterproofing DWG Block for AutoCAD

Basement Waterproofing DWG Block for AutoCAD

Basement water proofing with draining tubo.

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

reinforced concrete wall, drainage tube, drainage formed by fine gravel of granulometry, prefabricated concrete, waterproofing sheet, reinforced slab, fine gravel, compacted soil

Raw text data extracted from CAD file:

Muro hormigón armado \W1.81721; Tubo de drenaje \W0.38315; Drenaje \W0.38315; formado \W0.38896; por grava fina \W0.38896; de \W5.34739; granulometría \W7.11560; 4-32mm Prefabricado de hormigón Lámina de impermeabilización Losa armada Grava fina \W1.05188; Suelo compactado

Language	Spanish
Drawing Type	Block
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials	Concrete
Measurement Units
Footprint Area
Building Features
Tags	autocad, basement, béton armé, block, concrete, DWG, formwork, proofing, reinforced concrete, schalung, stahlbeton, water, waterproofing
