Camera Bt A-3 DWG Block for AutoCAD

Camera Bt A-3 DWG Block for AutoCAD

Camera BT A-3-Plant – Views – Enclosed measures

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

max., chest, plant, tube mm., min. max., section, concrete block, vibrated cm., nerves, unelco, to. t.

Raw text data extracted from CAD file:

\A1;0.96 \A1;Min. 1.10 Max. 1.30 \A1;Min. 0.80 Max. 1.00 \A1;0.71 \A1;0.66 \A1;0.07 \A1;0.86 \A1;0.07 \A1;0.15 \A1;0.72 ARQUETA A-3 A B PLANTA TUBO d160 mm. TUBO d160 mm. TUBO d160 mm. 5 Min. 1.10 Max. 1.30 Min. 0.80 Max. 1.00 SECCION A-B BLOQUE DE HORMIGON VIBRADO 50x25x12 cm. 4 NERVIOS 50 20 0.71 5 5 5 5 5 5 Unelco A. T.

Language	Spanish
Drawing Type	Block
Category	Mechanical, Electrical & Plumbing (MEP)
Additional Screenshots
File Type	dwg
Materials	Concrete
Measurement Units
Footprint Area
Building Features
