Chimney Detail – Roof Ghtter DWG Detail for AutoCAD

Chimney Detail – Roof Ghtter DWG Detail for AutoCAD

Detail chimney – Connection roof with chimney – Technical specifications

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Used concrete cutter, Ruana cap seals in galvanized sheet, Canoe in galvanized sheet, developmental, Roof shingles under redoblon shingles, Roof tile, Redoblon tile, Mortar and pestle, Waterproofing covering the canoe, Tongue and groove, Wood door knob, Mortar half cane, Revoke, With clavera every, sheet, Masonry wall, Sleeping sill in fixed wood, Canoe against attic wall

Raw text data extracted from CAD file:

CORTAGOTERAS PREFABRICADA EN CONCRETO RUANA TAPA JUNTAS EN LAMINA GALVANIZADA CAL.24 CANOA EN "L" EN LAMINA GALVANIZADA CAL.26 100m DE DESARROLLO CASQUETES DE TEJA BAJO LAS TEJAS REDOBLON TEJA CANAL TEJA REDOBLON MORTERO DE PEGA DE LAS TEJAS CANAL IMPERMEABILIZACION CUBRIENDO LA CANOA TABLILLA MACHIHEMBRADA ALFARDA EN MADERA MORTERO A MEDIA CAÑA REVOQUE CON CLAVERA CADA 100m CHAPA MURO EN MAMPOSTERIA SOLERA O DURMIENTE EN MADERA FIJADA CANOA EN "L" ( contra muro ático )

Language	Spanish
Drawing Type	Detail
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials	Concrete, Masonry, Wood
Measurement Units
Footprint Area
Building Features
Tags	autocad, barn, chimney, connection, cover, dach, DETAIL, DWG, hangar, lagerschuppen, roof, shed, specifications, structure, technical, terrasse, toit
