Crane Bridge Complete DWG Detail for AutoCAD

Crane Bridge Complete DWG Detail for AutoCAD

Pplanta, elevation, cut, details

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

shaft, beam, rail track, typical traveling cable, anchor bolts and elements, designed by the contractor and, supplied by others., festoon., conductor crown, rail anchor detail, section b, rail-way, led beam, office area, step, outside air, assembly room, rail track, fixed stop for, crane, typ., crane beam, concrete, typ., bridge crane, carriage, damper, typ ., section c, step rail, anchor bolts

Raw text data extracted from CAD file:

EJE DEL Viga G1 C riel via Cable viajero típo Pernos de anclaje y elementos diseñado por el Contratista y embebidos en concreto primario; 2053,00 suministrado por otros. G2 festón. Corona del Viga conductora 600 600 DETALLE DE ANCLAJE DEL RIEL C C 200 200 600 1000 SECCIÓN B RIEL-VIA Viga conducida 400 ZONA DE OFICINAS 2047.00 Buitrón para paso de aire exterior SALA DE MONTAJE Riel via Tope fijo para la grúa, típ. Viga grúa de concreto, típ. Puente grúa Carro Luz = 10.300 B B H1 Amortiguador, típ. H2 SECCIÓN C Pisa riel Pernos de anclaje Pisa riel 10.30 Puente grúa 10% 11.10 H 10%

Language	Spanish
Drawing Type	Detail
Category	Industrial
Additional Screenshots
File Type	dwg
Materials	Concrete, Other
Measurement Units	Metric
Footprint Area
Building Features
