Detail Steel Handrail DWG Section for AutoCAD

Detail Steel Handrail DWG Section for AutoCAD

Steel handrail – Section – Plant – Axonometry

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Pacific university, subject:, student:, semester:, cod, teacher:, content:, date:, scale:, plan no, faculty architecture, steel, riser rail, steel cable holder, steel wire, screw s, bolted plates main structure, finished floor, fixing screw for main frame, anchor bolt s, cut rail detail, screw to press steel cable, stainless steel hands-on, anchorage, flat screw, platinum bond s, metal separators upright, barral stainless steel, axonometria railing detail, corridor detail

Raw text data extracted from CAD file:

UNIVERSIDAD DEL PACIFICO ASIGNATURA: ALUMNO: SEMESTRE: COD: DOCENTE: CONTENIDO: FECHA: ESCALA: PLANO Nº FACULTAD ARQUITECTURA Pasa Manos AceroInoxidable 2" Montante de Baranda Platinas 16mm Soporte Cable Acerado 10mm Cable Acerado 10mm Tornillo Anclaje Elemento Fijación Cable Acerado a Montantes Platinas Atornillada a Estructura Principal Piso Con Acabado Tornillo para Fijación de Montante a Estructura Principal Tornillo Anclaje Pasamano - Montante DETALLE CORTE BARANDA Tornillo para Presionar Cable Acero Pasa Manos Acero Inoxidable 2" Anclaje Pasamanos - Montantes Tornillo Rosca Plana Platina Vinculación Montante - estructura Principal Separadores Metálicos Montante Barral Acero inoxidable DETALLE AXONOMETRIA BARANDA DETALLE BARANDA PASILLO
