Detailed Two-Story House DWG Detail for AutoCAD

Detailed Two-Story House DWG Detail for AutoCAD

Straightedge of a two-story house designed in wood deck details, earth and skies

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

structural, bottom pin, water rain width mm, Pine tree, vertical, thermal, exp. high density, structural mm, Pine tree, acoustic, of cellulose, structural mm, gypsum carton mm, horizontal, structural mm., galvanized steel bolts mm, of tarred paper smoke, acoustic, of cellulose, structural mm, Pine tree, acoustic leveler mm, mm beech laminate, structural mm, Pine tree, acoustic leveler mm, mm beech laminate, thermal, exp. high density, structural mm, moisture, of polyethylene, poor concrete, south facade, metal liner, upper pine sill, outer jacket pine thickness mm, zinc corrugated iron, moisture barrier paper tarred paper, structural plywood mm., upper pine sill, pine chain, insulating mineral wool, bottom pin, Pine tree, galvanized steel bolts mm, upper pine sill, pine chain, bottom pin, Pine tree, impregnated wood, galvanized steel bolts mm., base mm, bolts mm., he has. cm design, upper pine sill, insulating mineral wool, moisture polyethylene film

Raw text data extracted from CAD file:

\W9.45447; \A1;TERCIADO ESTRUCTURAL 15MM \W8.83978; \A1;SOLERA INFERIOR PINO 2"X 6" \W9.99116; \A1;CANAL DE AGUA LLUVIA ANCHO 100 MM \W7.53737; \A1;VIGA PINO 2" X 6" \A1;COSTANERA PINO 2" X 4" \A1;PIEZA VERTICAL PINO 2" X 4" \A1;AISLAMIENTO TERMICO \A1;POLIESTIRENO EXP. ALTA DENSIDAD 5OMM \A1;TERCIADO ESTRUCTURAL 15 MM \A1;VIGA PINO 2"X 6" \A1;AISLAMIENTO ACUSTICO \A1;PANAL DE CELULOSA 4OMM \A1;TERCIADO ESTRUCTURAL 15 MM \A1;PLANCHA YESO CARTON 10 MM \A1;PIEZA HORIZONTAL PINO 2" X 4" \A1;TERCIADO ESTRUCTURAL 20 MM. \W9.51340; \A1;PLETINA ACERO GALVANIZADO C/ 6 PERNOS Ø 12 MM \A1;BARRERA DE HUMADAD PAPEL ALQUITRANADO (15lb) \A1;AISLAMIENTO ACUSTICO \A1;PANAL DE CELULOSA 4OMM \A1;TERCIADO ESTRUCTURAL 15 MM \A1;VIGA PINO 2"X 6" \A1;AISLANTE ACUSTICO NIVELADOR 3 MM \A1;PLANCHA YESO-CARTON 10 MM \A1;PISO LAMINADO DE HAYA DE 8 MM \A1;TERCIADO ESTRUCTURAL 15 MM \A1;VIGA PINO 2"X 6" \A1;AISLANTE ACUSTICO NIVELADOR 3 MM \A1;PISO LAMINADO DE HAYA DE 8 MM \A1;AISLAMIENTO TERMICO \A1;POLIESTIRENO EXP. ALTA DENSIDAD 5OMM \A1;TERCIADO ESTRUCTURAL 15 MM \A1;BARRERA DE HUMEDAD \A1;LAMINA DE POLIETILENO \A1;EMPLANTILLADO HORMIGON POBRE \A1;ESC 1 : 10 \A1;ESCANTILLON 3 FACHADA SUR FORRO METALICO SOLERA SUPERIOR PINO 2"X6" REVESTIMIENTO EXTERIOR PINO ESPESOR 25 mm PLANCHA ACANALADA ZINC 5V BARRERA HUMEDAD PAPEL FIELTRO ALQUITRANADO (15 lb) TERCIADO ESTRUCTURAL 20 mm. SOLERA SUPERIOR PINO 2"X6" CADENETA PINO 2"X6" LANA MINERAL AISLANTE TERMO-ACUSTICO \W8.83978; \A1;SOLERA INFERIOR PINO 2"X 6" \W7.53737; \A1;VIGA PINO 2" X 6" \W9.51340; \A1;PLETINA ACERO GALVANIZADO C/ 6 PERNOS Ø 12 MM SOLERA SUPERIOR PINO 2"X6" \W8.43866; \A1;GUARDAPOLVO 3/4" X 6" CADENETA PINO 2"X6" CADENETA PINO 2"X6" CADENETA PINO 2"X6" \W8.43866; \A1;GUARDAPOLVO 3/4" X 6" \W8.83978; \A1;SOLERA INFERIOR PINO 2"X 6" \W7.53737; \A1;VIGA PINO 2" X 6" \W8.91568; \A1;ROLLIZO DE MADERA IMPREGNADA \W9.40954; \A1;PLETINA ACERO GALVANIZADO C/4 PERNOS Ø 12 mm. \W9.00103; \A1;PL BASE 200 X 170 X 6 mm \W9.37703; \A1;L=400 C/GANCHO 2 PERNOS Ø 12 mm. \W9.42325; \A1;FUNDACION H.A. 65 X 50 CM DISEÑO S/CALCULO SOLERA SUPERIOR PINO 2"X6" LANA MINERAL AISLANTE TERMO-ACUSTICO \W9.65263; \A1;BARRERA DE HUMEDAD LAMINA DE POLIETILENO \A1;NPT +0.50 \A1;NNT ±0.00 \A1;NPT +3.50

Language	Spanish
Drawing Type	Detail
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials	Concrete, Steel, Wood
Measurement Units
Footprint Area
Building Features	Deck / Patio
