Details Cerchas DWG Detail for AutoCAD

Details Cerchas DWG Detail for AutoCAD

Details – specifications – sizing – Construction cuts

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

truss detail, esc., enamel zinc cover. lime, galv steel strollers. from c.a.c, smooth zinc ridge enamel. lime, wheel aligners. from c.a.c, cabbage, connection of cabbage, esc., det. truss, esc., tubes, connection of truss, det. truss, esc., tubes, tubes, thermal insulation, esc.

Raw text data extracted from CAD file:

\A1;.40 \A1;45° \A1;.40 \A1;.30 \A1;45° \A1;.30 \A1;.40 \A1;.61 \A1;45° DETALLE DE CERCHA CT-1 ESC. 1:10 CUBIERTA DE ZINC ESMALT. CAL 26 CARRIOLAS DE ACERO GALV. DE 6" X 2" CAL.16 @ ± 1.00 c.a.c CUMBRERA DE ZINC LISO ESMALT. CAL 26 CT-1 ALINEADORES DE CARR. DE 1/2" d @ L/2 c.a.c P L 6" X 6" X 5/8" X A/ C 6" X 10" X 1/2" P L CT-1 CT-1 COL'S 0.30 X 0.30 (VER DET.) CONEXION DE CT-1 @ COL'S ESC. 1:10 5 5 5 DET. DE CERCHA DE AMARRE (CA) ESC. 1:10 5 5 TUBOS 1" X 1" X 3/16" CONEXION DE CERCHA (CA) @ CERCHA CT-1 CT-1 5 5 CA DET. DE CERCHA CT-2 ESC. 1:10 TUBOS 2" X 2" X 3/16" 5 5 TUBOS 2" X 2" X 3/16" TUBOS 1" X 11/2" X 3/16" AISLANTE TERMICO ESC. 1:10

Language	Spanish
Drawing Type	Detail
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials	Steel
Measurement Units
Footprint Area
Building Features
Tags	autocad, barn, construction, cover, cuts, dach, DETAIL, details, DWG, hangar, lagerschuppen, metal cover, roof, shed, sizing, specifications, structure, terrasse, toit, trusses
