Details Wall Of Contention DWG Detail for AutoCAD

Details Wall Of Contention DWG Detail for AutoCAD

Intermission connection beam –
wall

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

variable, variable, of stirrups according to calculation., cross chain, armed wall, prefabricated neoprene gasket, of thickness, on sidewalk, cross chain, beam, clean saturated with water, before straining, casting board, armed wall, Earth, variable, variable, Intermediate link in flat beam wall over shoulder on sidewalk., mechanically consider the union as simple support. It is advisable to use a neoprene band of mm at the base of the union

Raw text data extracted from CAD file:

00.00 Variable 0.30 B+0.10 Variable 0.05 B Lb 0.20 Lb 2 Lb *Separacion de estribos segun calculo. CADENA TRANSVERSAL ARMADO MURO JUNTA PREFABRICADA DE NEOPRENO 5MM DE ESPESOR SOBRE BANQUETA CADENA TRANSVERSAL VIGA LIMPIA Y SATURADA DE AGUA ANTES DE COLAR JUNTA DE COLADO ARMADO MURO TIERRA 2 Lb Lb 0.20 Lb B 0.05 Variable B+0.10 0.30 Variable Enlace intermedio en muro de viga plana sobre resalto en banqueta. Considerar mecánicamente la unión como apoyo simple. Es recomendable usar una banda de neopreno de 5 mm en la base de la unión forjado/re

Language	Spanish
Drawing Type	Detail
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials
Measurement Units
Footprint Area
Building Features
Tags	autocad, beam, béton armé, concrete, connection, contention, DETAIL, details, DWG, formwork, reinforced concrete, schalung, stahlbeton, wall
