Different Layers – Impermeabilizacion DWG Detail for AutoCAD

Different Layers – Impermeabilizacion DWG Detail for AutoCAD

Details – specifications – sizing – Construction cuts

Drawing labels, details, and other text information extracted from the CAD file (Translated from Galician):

typical detail, j.c., ntc, layers of waterproofing thermoteck, symbols for, waterproofing, surface cleaning application, layer of thermoteck seal, thermoteck waterproofing layer, reinforced polyester membrane layer, est., nsp., esc., stuffed with, cement sand, perlila, expanded

Raw text data extracted from CAD file:

DETALLE TIPICO No.1 \A1;120 J.C. NTC. 105.000 2 CAPAS DE IMPERMEABILIZANTE TERMOTECK MAX-10 SIMBOLOGIA PARA IMPERMEABILIZACION LIMPIEZA DE LA SUPERFICIE Y APLICACION CAPA DE THERMOTECK SELLO (TAPAPORO) CAPA DE IMPERMEABILIZANTE TERMOTECK MAX.-10 CAPA DE MEMBRANA POLIESTER REFORZADO MAX-10 5 3 4 2 1 \A1;1400 200 \A1;600 EST. #3 @200 500 (TIPO) \A1;600 VR #3 (A.S.) NSP. 105.600 ESC. 1:20 (A.S.) VR #4 1 2 3 4 5 \A1;1000 \A1;250 RELLENO CON CEMENTO ARENA 1:4 Y PERLILA EXPANDIDA
