Facade Section Construction Detail DWG Section for AutoCAD

Construction detail cutting facade

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

guest bedroom, outdoor garden, children’s room, bedroom, loose gravel, waterproofing with imperconcrete, aluminum flashing, tuscan shot, concrete wall ocher the view, cutter deck slab according to structural design finish tuscan cutter bottom in concrete the view wall in concrete ocher the view detached in door sliding window in aluminum finish in carpet floor finish in floor in wood slats teka screwed tarugados top shot steel sheet bent painting polyurethane on epoxy anticorrosive base wall in concrete ocher the view on the inner side of the drainage of drainage water rains exterior plinth with phenolic triplex off-hook in internal wall in dry interior according to details of bathrooms, nf ne nf, wood floor finish granadillo la cado natural tuscan finish cm cm board edge in concrete ocher the view, facade section

Raw text data extracted from CAD file:

Alcoba huespedes Jardín exterior Alcoba niños alcoba p/pal Gravilla suelta Impermeabilizacion con imperconcreto Flashing en aluminio Remate toscano (1cm x 1cm) Muro en concreto ocre a la vista Cortagoterero Losa de cubierta segun diseño estructural Remate toscano cortagoterero Cielo-raso-torta inferior en concreto a la vista Muro en concreto ocre a la vista Cielo-raso descolgado en dry-wall Puerta ventana corredera en aluminio Acabado en piso de alfombra Acabado en piso en listones de madera teka atornillados y tarugados Remate superior lamina de acero doblada pintura poliuretano sobre base anticorrosiva epoxica muro en concreto ocre a la vista por la cara interna Cañuela de desaguede aguas lluvias Enchape exterior con triplex fenolico Cielo-raso descolgado en dry-wall Muro interno en dry wall,acabado interior segun detalles de baños NF = + 7.25 NE = - - - - - NF = - - - - NE= + 6.55 NF= + 3.50 NE= + 0.45 NF= + 0.50 NE= +0.45 NF= - 2.55 NE= - 2.60 acabado de piso en madera granadillo la cado natural remate toscano ( 1 cm x 1 cm ) borde de placa en concreto ocre a la vista Sección fachada

Language	Spanish
Drawing Type	Section
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials	Aluminum, Concrete, Steel, Wood
Measurement Units
Footprint Area
Building Features	Deck / Patio, Garden / Park
Tags	autocad, construction, construction details section, cut construction details, cutting, DETAIL, DWG, facade, section
