Farnsworth House DWG Block for AutoCAD

Farnsworth House DWG Block for AutoCAD

House farnsworth – General Plant – height

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

cut, south elevation esc, elevation esc, elevation north esc, elevation this esc, casa farnsworth this house takes advantage of many passive systems. It has south orientation to take advantage of sunlight. owns deciduous vegetation for solar protection thermal barrier towards the facades west south. It is raised from the ground to allow a cooling by convection. the roof is made up of insulating thermo-statues that trap the heat and distribute it avoiding heating. It has low vents in the eastern façade that allows it to cool the interior by direct ventilation., insulating, ceiling with thermostat, elevated, low vents, architectural floor scenic

Raw text data extracted from CAD file:

\A1;6.50 \A1;6.25 \A1;5.60 \A1;6.45 \A1;24.80 \A1;8.40 \A1;6.70 \A1;15.10 XX XX 1 2 3 4 5 A B C 0 0 0 0 0 0 0 0 CORTE A CORTE B ELEVACION SUR Esc 1:100 ELEVACION 0ESTE Esc 1:100 ELEVACION NORTE Esc 1:100 ELEVACION ESTE Esc 1:100 CASA FARNSWORTH Esta casa aprovecha muchos sistemas pasivos. 1. Tiene orientación sur para aprovechar asoleamiento. 2. Posee vegetación caduciforme para proteccion solar y barrera térmica hacia las fachadas oeste y sur. 3. Está elevada del suelo para permitir un enfriamiento por convección. 4. El techo está conformado por termoestatos y aislantes que atrapan el calor y lo distribuyen uniformemente, evitando el calentamiento. 5. Posee ventilas bajas en la fachada oriente que le permite refrescar el interior por ventilación directa. \A1;Techo aislante Techo con termostato \A1;Plataformas elevadas Ventilas Bajas PLANTA ARQUITECTÓNICA Esc 1:100

Language	Spanish
Drawing Type	Block
Category	Famous Engineering Projects
Additional Screenshots
File Type	dwg
Materials
Measurement Units
Footprint Area
Building Features
