Fire Protection – Simbols

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Fire alarm panel., Smoke detector type ionization., Heat detector., End of line resistance. Will be at the end of each, Manual fire extinguisher, Self-rising electronic buzzer bell., Father, Rfl, System symbology, Fire escape box, Zone to allow automatic supervision., Cpi, fire protection, Battery smoke detector., Dhb

Raw text data extracted from CAD file:

PANEL DE ALARMA CONTRA INCENDIOS. DETECTOR DE HUMO TIPO IONIZACION. DETECTOR DE CALOR. RESISTENCIA DE FIN DE LINEA. ESTARAN AL FINAL DE CADA ESTACION MANUAL CONTRA INCENDIO (DE 2 ETAPAS). CAMPANA AUTOVIBRANTE DE 6"d O ZUMBADOR ELECTRONICO. PAI H C RFL M SIMBOLOGIA DE SISTEMA CAJA DE PASO DE INCENDIO (8"x8"x4"). ZONA PARA PERMITIR LA SUPERVISION AUTOMATICA. CPI CONTRA INCENDIOS DETECTOR DE HUMO DE BATERIA. DHB
