Floating Cover DWG Section for AutoCAD

Floating Cover DWG Section for AutoCAD

Union wall curtain – Section

Drawing labels, details, and other text information extracted from the CAD file (Translated from Galician):

roof suspended, forged semitreakers ceramic swirls, leveling layer, of each wood, Thermal insulation between traces, floor consisting of wooden platform, machihembradas of, Rigid plates of extruded polystyrene, protective mortar layer, waterproofing butyl rubber paint, cut off on omega, Floating cover formed by steel plate, roof suspended, forged semitreakers ceramic swirls, light concrete for slope:, respective armed, beam of change of height with its, painted in white, painted concrete slab, profile, the slab of reinforced concrete, steel bracket cut anchored, closing profile lpn, neoprene joint, double glazing, plastic connectors, upper lower, overhanging the armed slab with its armed forces, cutting steel plate cut, plaster double component, scale, blank, painted concrete slab, tubular profile, concrete wall reinforced, Projected polyurethane, on racks, steel plate conrten, profile, Projected polyurethane, tubular profile, cut on racks profile lpn, curtain wall made of steel plate, profile, stainless steel gutter, scale, Curtain wall formed by corten steel plate, on profile frames lpn, tubular profile, Projected polyurethane, beam of change of quota, cement plaster painted in white, floating cover formed by steel sheet cut, of omegas of corten steel, waterproofing butyl rubber paint, protective mortar layer, Rigid plates of extruded polystyrene, light concrete for slope:, corrugated slab of armor, roof suspended, mallazo every negative beam, forged semitreakers ceramic swirls, connector, profile, lower arm slab, armed beam, armed top slab, stainless steel gutter, rectangular profile

Raw text data extracted from CAD file:

TECHO SUSPENDIDO FORJADO DE SEMIVIGUETAS Y BOVEDILLAS CERAMICAS CAPA DE NIVELACION DE MADERA DE 4O*30mm CADA 50cm Y AISLAMIENTO TERMICO DE e=32mm ENTRE RASTRELES SUELO FORMADO POR TARIMA DE MADERA DE e=15mm MACHIHEMBRADAS DE e=4cm PLACAS RIGIDAS DE POLIESTIRENO EXTRUIDO CAPA DE MORTERO DE PROTECCION IMPERMEABILIZANTE Y PINTURA DE CAUCHO BUTILO CORTEN DE e=1cm SOBRE OMEGAS CUBIERTA FLOTANTE FORMADA POR CHAPA DE ACERO TECHO SUSPENDIDO FORJADO DE SEMIVIGUETAS Y BOVEDILLAS CERAMICAS HORMIGON LIGERO PARA PENDIENTE: 1-2% RESPECTIVOS ARMADOS VIGA DE CAMBIO DE COTA CON SUS PINTADO EN BLANCO ENFOSCADO DE CEMENTO PINTADO PERFIL 80*40*5mm LA LOSA DO HORMIGON ARMADO SOPORTE DE ACERO CORTEN ANCLADO A PERFIL DE CIERRE LPN 30*30*5mm JUNTA DE NEOPRENO VIDRIO CLIMALIT 6+6+6mm CONECTORES DE PLASTICO SUPERIOR E INFERIOR VOLADIZO DE LOSA ARMADA CON SUS ARMADOS CHAPA DE REMATE DE ACERO CORTEN 145*50*8mm REVOCO DOBLE COMPONENTE ESCALA 1/20 EN BLANCO ENFOSCADO DE CEMENTO PINTADO PERFIL TUBULAR 40*40*5mm MURO DE HORMIGON ARMADO POLIURETANO PROYECTADO e=3cm SOBRE BASTIDORES CHAPA DE ACERO CONRTEN e=6mm PERFIL 80*40*5mm POLIURETANO PROYECTADO e=3cm PERFIL TUBULAR 40*40*5mm 30*30*5mm CORTEN e=6mm SOBRE BASTIDORES PERFIL LPN MURO CORTINA FORMADO POR CHAPA DE ACERO PERFIL 90*40*5mm CANALON DE ACERO INOXIDABLE ESCALA 1/5 MURO CORTINA FORMADO POR CHAPA DE ACERO CORTEN e=6mm SOBRE BASTIDORES DE PERFIL LPN 30*30*5mm PERFIL TUBULAR 40*40*5mm POLIURETANO PROYECTADO e=3cm VIGA DE CAMBIO DE COTA ENFOSCADO DE CEMENTO PINTADO EN BLANCO CUBIERTA FLOTANTE FORMADA POR CHAPA DE ACERO CORTEN DE e=6mm SOBRE OMEGAS DE ACERO CORTEN IMPERMEABILIZANTE Y PINTURA DE CAUCHO BUTILO CAPA DE MORTERO DE PROTECCION PLACAS RIGIDAS DE POLIESTIRENO EXTRUIDO e=6mm HORMIGON LIGERO PARA PENDIENTE: 1-2% VOLADIZO DE LOSA DE ARMADO TECHO SUSPENDIDO MALLAZO 0 8mm cada 15cm + NEGATIVO VIGUETA FORJADO DE SEMIVIGUETAS Y BOVEDILLAS CERAMICAS CONECTOR PERFIL 80*40*5mm ARMADO INFERIOR LOSA ARMADO VIGA ARMADO SUPERIOR LOSA CANALON DE ACERO INOXIDABLE PERFIL RECTANGULAR 90*40*5mm

Language	N/A
Drawing Type	Section
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials	Concrete, Plastic, Steel, Wood
Measurement Units
Footprint Area
Building Features
Tags	abgehängten decken, autocad, ceiling, cover, curtain, DWG, floating, plafonds suspendus, section, suspenden ceilings, union, wall
