Floating Floor Detail DWG Section for AutoCAD

Floating Floor Detail DWG Section for AutoCAD

It is detailed in section; as is the assembly of a floating floor with Constructive elements to be used. The detail in the union with the slab and the wall is shown; to also show the assembly of the sockets and elements of adherence.

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

sections floating floor, acoustic elastic band, unidirectional forged, double hollow brick, pyl, lower channel, plaster plaster, vertical section, acoustic band behind socket, plinth, sealed under socket, compression layer, plastic film, mortar glue, ceramic finish, sections floating floor, acoustic elastic band, unidirectional forged, double hollow brick, pyl, lower channel, plaster plaster, acoustic band behind socket, plinth, sealed under socket, compression layer, plastic film, mortar glue, ceramic finish

Raw text data extracted from CAD file:

SECCIONES SUELO FLOTANTE ROCKCALM-E 211 BANDA ELÁSTICA ACÚSTICA FORJADO UNIDIRECCIONAL LADRILLO HUECO DOBLE PYL CANAL INFERIOR ENLUCIDO YESO SECCIÓ VERTICAL 1/25 BANDA ACÚSTICA DETRÁS ZÓCALO ZÓCALO SELLADO BAJO ZÓCALO CAPA COMPRESIÓN FILM PLÁSTICO ROCKSOL-E-501 MORTERO COLA ACABADO CERÁMICO SECCIONES PISO FLOTANTE ROCKCALM-E 211 BANDA ELÁSTICA ACÚSTICA FORJADO UNIDIRECCIONAL LADRILLO HUECO DOBLE PYL CANAL INFERIOR ENLUCIDO YESO BANDA ACÚSTICA DETRÁS ZÓCALO ZÓCALO SELLADO BAJO ZÓCALO CAPA COMPRESIÓN FILM PLÁSTICO ROCKSOL-E-501 MORTERO COLA ACABADO CERÁMICO

Language	Spanish
Drawing Type	Section
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials	Plastic
Measurement Units
Footprint Area
Building Features
Tags	ASSEMBLY, assoalho, autocad, constructive, deck, DETAIL, detailed, DWG, elements, fliese, fließestrich, floating, floating floor, floor, flooring, fußboden, holzfußboden, piso, plancher, plancher flottant, section, tile, union
