Gas Box Packaging DWG Block for AutoCAD

Gas Box Packaging DWG Block for AutoCAD

Box packaging for two gas cylinders; executed in common brick masonry lime plasters and structural work

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

references:, kg carafe, pressure regulator, flexible, door with ventilation, front gas box esc., cut gas box esc.

Raw text data extracted from CAD file:

\A1;1.50 \A1;0.15 \A1;1.20 \A1;0.15 \A1;1.50 \A1;0.05 \A1;1.20 \A1;0.90 \A1;0.60 \A1;0.15 \A1;0.90 4 Referencias: 1 Garrafa de 45 kg 2 Regulador de presion 3 Flexible de bronce, 4 Puerta metalica, doble, con ventilacion s/norma. 4 3 2 1 1 1 2 4 3 FRENTE CASILLA DE GAS esc. 1:100 CORTE CASILLA DE GAS esc. 1:100 5 5 5 5 5 5 5 5 5 5 5

Language	Spanish
Drawing Type	Block
Category	Mechanical, Electrical & Plumbing (MEP)
Additional Screenshots
File Type	dwg
Materials	Masonry
