Grill camera with A.LL, – Mud brick

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

polished, section, mud brick, skull type, loop post, base of, simple concrete, half channel, pvc output, pipeline, arrival, pvc, detail, concrete, frame of, detail, full of, plate of, iron cm, skull type, mud brick, loop post, detail, grill box, plant, npt, pvc output, pipeline, section, simple concrete, base of, loop post, mud brick, peeled, tuned up, box with grill a.ll., scale, concrete, cms, pl. lam ho, anchors, cms, variable, your B., your B, pl. lam ho, cms, its T., half-cane, channel, cms, pl. lam ho

Raw text data extracted from CAD file:

\A1;VARIABLE \A1;0.15 \A1;0.30 \A1;0.15 \A1;0.15 \A1;0.30 \A1;0.60 \A1;0.15 \A1;0.025 \A1;h=VARIABLE \A1;0.025 \A1;0.60 0.025 REPELLADO Y PULIDO SECCION A < 1½" X 1½" X 1/16" LADRILLO DE BARRO TIPO CALAVERA PUESTO DE LAZO BASE DE CONCRETO SIMPLE CANAL MEDIA CAÑA SALIDA PVC d 6" TUBERIA DE LLEGADA PVC d NT= DETALLE A CONCRETO MARCO DE < 1½" X 1½" X 1/8" DETALLE A d 3/8" LLENO DE PLETINA DE 3/4"X1/8" O HIERRO d1/2" @ 2.5 cm TIPO CALAVERA LADRILLO DE BARRO PUESTO DE LAZO DETALLE A A CAJA PARRILLA PLANTA NPT 1% SALIDA PVC d TUBERIA DE SECCION A CONCRETO SIMPLE BASE DE PUESTO DE LAZO LADRILLO DE BARRO REPELLADO Y AFINADO CAJA CON PARRILLA A.LL. ESCALA 1 : 10 \A1; 5 5 5 5 5 5 5 5 \A1; CONCRETO NF= 2 % 2 % f'=210 kg/cm e=3/16" @ 2.5 cms PL. LAM. Ho. < 2" x 2" x 3/16" ANCLAS d 3/8" @ 20 cms < 2"x2"x1/4" VARIABLE h=VARIABLE f'=210 kg/cm < 2" x 2" x 3/16" < 1½" X 1½" X 1/16" TUB. d TUB d PL. LAM. Ho. e=3/16" @ 2.5 cms 3 d 3/8" EST. d¼" @ 0.15 EST. d¼" @ 0.15 3 d 3/8" MEDIA CAÑA CANAL <>5 e=3/16" @ 2.5 cms PL. LAM. Ho. < 1½" X 1½" X 1/16" B
