Exploded isometric a swim in; materials and specifications

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

architecture facuilty, autonomous University, From yucatán, project’s name, Bathroom scrap, Environment project workshop, observations:, Symbology, Hdr, Dimension, date of delivery, scale:, Exploded view of a house-type bathroom, Contains:, Br. Juan abraham baas moreno, design:, flat, teacher:, Observations of the project:, Wide wall cloths, Finishing of bathroom finishes, Bathroom valance torino arni interceramic cm plates, Grinding line brussels interceramic, Quarry macedonia, Cantera cream, Quarry ticul golden quarry boards, Porcelanato rectificado linea astrato interceramic plaques, Finish box, Porcelanato rectificado linea astratto interceramic plates, Single lever helvex arssen aai, Future sprinkler, Helvex diamond handle, Bathroom mirror first aid kit, W.c. Helvex bolmen, Ania oval washbasin, Louis snt cabinet, Castel bathroom cancellation, Check finishing annex, Arq. Maria guadalupe duran gonzalez

Raw text data extracted from CAD file:

FACULTAD DE ARQUITECTURA UNIVERSIDAD AUTÓNOMA DE YUCATÁN NOMBRE DEL PROYECTO DESPIECE DE BAÑO TALLER DE PROYECTOS MEDIO AMBIENTE 1:100 Observaciones: 14/05/12 1 de 1 SIMBOLOGÍA Hdr Acotación Fecha de entrega Escala: Despiece de un baño de casa tipo Contiene: Br. Juan Abraham Baas Moreno Diseño: Plano Profesor: observaciones del proyecto: a ejes, anchos de muros y paños despiece de acabados de baño 0.00 0.90 2.40 PS-01 0.00 0.90 2.40 PS-01 cenefa para baño Torino Arni interceramic - placas de 10 x 30 cm 1.50 0.80 0.80 VA-04 1.50 0.80 0.80 VA-04 -porcelanato rectificado linea bruselas interceramic -placas de 30x 60 cantera Macedonia - placas de cantera macedonia de 40 x 40 cantera Crema maya - placas de cantera crema maya de 40 x 40 cantera ticul dorada - placas de cantera de 40 x 40 porcelanato rectificado linea astrato interceramic - placas de 20 x 20 porcelanato rectificado linea astrato interceramic - placas de 20 x 20 2 3 4 5 6 1 7 8 9 10 3 4 5 6 CUADRO DE ACABADOS \C7;baño 2 1 5 6 6 1 porcelanato rectificado linea Astratto interceramic - placas de 20 x 30 monomando Helvex Arssen E-903 - AAI Regadera Futura RM-7 10 Maneral Helvex diamante C-3 Espejo de baño botiquin W.C. Helvex Bolmen 2 TT2-3 11 12 13 9 11 12 8 8 lavabo ANIA oval 14 13 14 1 1 13 5 5 5 6 6 6 2 3 4 Gabinete Snt Louis 15 15 15 9 12 14 10 16 16 16 cancel de baño CASTEL vERIFICAR ANEXO DE ACABADOS Arq. Maria Guadalupe Duran Gonzalez
