Housing Light Wall DWG Detail for AutoCAD

Detail of light wall for housing – Details , specifications

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

minimum, minimum, publish, medidior, plant view, via, property, of the user, detail of recessed base, volts, plastic seal., ring for base stainless steel plug., meter type amp plug. threads, installed by c.f.e., meter the hoop., wall of, concrete, base plug, ring, of the wall to place the, this should come out at least, when embedding the base plug, installation, inside, rod, Earth, from the base, neutral, phase, Plug, switch, wiring detail of the base, Interferie of diam. galvanized iron conduit pipe thick wall of diam. with length. copper wire thw caliber from the mufa to the liner of the neutral conductor white color of the phase other than white. base amperes plug. amperes thermomagnetic switch. reduction of conduit thin wall diam. minimum wire copper wire. connector for ground rod. ground rod for a max resistance. of ohms. murete according to the indicated., material equipment specifications, of the, rush, user’s charge, the preparation to receive the connection must be, as maximum mts. of the post from which, will give the service., the neutral conductor must connect directly, the load without going through any means of protection, the preparation to receive the connection must be at, boundary of embedded overlay., prevent the crossing crossing another terrain, building., The height of the mufa to receive the rush is, of mm., the switch will be a diastance no greater, mm of the meter., dial the official address number in the form, permanent., notes:, minimum, of length, minimum, concrete, low, inside, installation, armed, concrete, dipstick, installation, inside, minimum, side view, front view, overall view

Raw text data extracted from CAD file:

4800 2800 MINIMO 1800 220 MINIMO 220 MINIMO PUBLICA MEDIDIOR VISTA DE PLANTA VIA PROPIEDAD DEL USUARIO DETALLE DE EMPOTRADO DE LA BASE 120 VOLTS (F121) 14 SELLO DE PLASTICO. 13 ARO PARA BASE ENCHUFE DE ACERO INOXIDABLE. 12 MEDIDOR TIPO ENCHUFE DE 15 AMP. 1 FASE, 2 HILOS INSTALADO POR C.F.E. MEDIDOR Y EL ARO. MURO DE CONCRETO BASE ENCHUFE ARO 5mm DEL MURO PARA COLOCAR EL ESTA DEBERA SALIR COMO MINIMO AL EMPOTRAR LA BASE ENCHUFE A INSTALACION INTERIOR A VARILLA DE 7 TIERRA 4 6 13 5 DE LA BASE NEUTRO FASE F N ENCHUFE E INTERRUPTOR DETALLE DE ALAMBRADO DE LA BASE F N \A1;1 MUFA INTERPERIE DE 32mm (1 \S1#4;\H1.428x;") DE DIAM. 2 TUBO CONDUIT DE FIERRO GALVANIZADO PARED GRUESA DE 32mm (1 \H0.7002x;\S1#4;\H1.428x;") DE DIAM. Y CON 3000mm DE LONGITUD. 3 CABLE DE COBRE THW CALIBRE 8.367 mm2(8 AWG) DESDE LA MUFA HASTA EL INTERRUPTOR, EL FORRO DEL CONDUCTOR NEUTRO DE COLOR BLANCO Y EL DE LA FASE DIFERENTE AL BLANCO. 4 BASE ENCHUFE DE 4 TERMINALES, 100 AMPERES. 5 INTERRUPTOR TERMOMAGNETICO DE 2 POLOS, 1 TIRO, 250 VOLTS, 30 AMPERES. 6 REDUCCION DE 32mm(1 \H0.7002x;\S1#4;\H1.428x;") A 12.7mm (\H0.7002x;\S1#2;\H1.428x;"). 7 TUBO CONDUIT PARED DELGADA DE 12.7mm (\H0.7002x;\S1#2;\H1.428x;") DE DIAM. 8 ALAMBRE O CABLE DE COBRE CALIBRE 8.367mm2 (8 AWG) MINIMO. 9 CONECTOR PARA VARILLA DE TIERRA. 10 VARILLA DE TIERRA PARA UNA RESISTENCIA MAX. DE 25 OHMS. 11 MURETE DE ACUERDO A LO INDICADO. ESPECIFICACIONES DE MATERIALES Y EQUIPO DE LA ACOMETIDA 8 A CARGO DE DEL USUARIO A LA PREPARACION PARA RECIBIR LA ACOMETIDA DEBE ESTAR COMO MAXIMO A 35 mts. DEL POSTE DESDE EL CUAL SE DARA EL SERVICIO. B EL CONDUCTOR DEL NEUTRO DEBE DE CONECTARSE DIRECTO A LA CARGA SIN MEDIO PASAR POR ALGUN MEDIO DE PROTECCION (FUSIBLE o TERMOMAGNETICO). C LA PREPARACION PARA RECIBIR LA ACOMETIDA DEBE ESTAR AL LIMITE DE PROPIEDAD, EMPOTRADA o SOBREPUESTA. D EVITAR QUE LA ACOMETIDA CRUCE OTRO TERRENO o CONSTRUCCION. E LA ALTURA DE LA MUFA PARA RECIBIR LA ACOMETIDA ES DE 4800 mm. F EL INTERRUPTOR ESTARA A UNA DIATANCIA NO MAYOR A 500 mm DEL MEDIDOR. G MARCAR EL NUMERO OFICIAL DEL DOMICILIO EN FORMA PERMANENTE. NOTAS: C F E 4800 2800 MINIMO 1800 3 1 2 13 12 14 6 4 5 9 10 8 7 11 500 mm DE LONGITUD F N 220 MINIMO CONCRETO MURETE DE INTERIOR A INSTALACION ARMADO DE CONCRETO Y VARILLA A INSTALACION INTERIOR 220 MINIMO VISTA LATERAL VISTA FRONTAL VISTA DE CONJUNTO

Language	Spanish
Drawing Type	Detail
Category	Mechanical, Electrical & Plumbing (MEP)
Additional Screenshots
File Type	dwg
Materials	Concrete, Plastic, Steel, Other
