Hydroroad Terminal Metallic Structure – Details.

Drawing labels, details, and other text information extracted from the CAD file (Translated from Galician):

longitudinal cut, luminous warning panel, coffee …, coffee with … bytes, balloons, single, waterproofing in the lacquer, molded molded locker, asphalt blanket poly-layer, nononononon

Raw text data extracted from CAD file:

CORTE LONGITUDINAL PAINEL DE AVISO LUMINOSO LOJA 01 LOJA 02 café... Café com...Bytes LOJA 12 Bilheterias solo Brita h=30cm Impermeabilizantes na laje Aço: C.A. 60, com malha eletro-soldada marca: Gerdau SA. Concreto: fck: 180MPa, fornecedor: Concretex, e=: 150mm Laje Moldada in loco solo compactado h=30cm Largura: 800mm, espessura: 5mm soldada a quente "in loco" Manta Asfaltica POLY-CAPA, Argamassa de assentamento h=30 mm Proteção mecânica h=10 mm Piso de pedra Granito ( tipo, PEI, marca) 440x440mm, e=30mm nononononon

Language	Other
Drawing Type	Detail
Category	Transportation & Parking
