Kitchen Sink Block Library – 24 fixture Types for Plan Views

This comprehensive kitchen sink block collection provides 24 distinct sink fixture variations for architectural plan drawings. This library includes single-bowl, double-bowl, and specialty configurations with drainboard options in various orientations. Each sink block represents standard modular installations with precise millimeter measurements, allowing for accurate placement in countertop designs. Notable elements include circular and rectangular bowl geometries, integrated drainboards, and corner installation options. The blocks follow industry-standard symbology for plumbing fixtures, with drain locations clearly indicated. Particularly useful is the variety of configuration options—sinks with left, right, and dual drainboards accommodate diverse kitchen layout requirements without manual modification.
