Lateral Section Of Industrial Metallic Nave DWG Section for AutoCAD

Lateral Section Of Industrial Metallic Nave DWG Section for AutoCAD

Lateral section industrial metallic nave

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Shoe, Hot asphalt agglomerate, Watering primer, Artificial shine, Type brace, Dwarf concrete, Anchor bolts, Prelaced sheet finishing, license plate, Portico, Surface treatment with resin finish, Concrete screed, Double mesh, Galvanized sheet metal channel, stop, Galvanized sheet cover, Belt with an axle of the same thickness, Galvanized sheet, Prelaced sheet finishing, Prelaced sheet, Metal profile, Portico soldier

Raw text data extracted from CAD file:

\A1;0.06 \A1;0.20 \A1;1.10 \A1;1.10 \A1;1.10 \A1;1.10 \A1;3.00 \A1;1.20 \A1;1.10 \A1;5.90 -14.21885540690486 ZAPATA AGLOMERADO ASFALTICO EN CALIENTE (S-12) RIEGO IMPRIMACION 1.5Kg/m2 ZAHORRA ARTIFICIAL 5 -1.353150913129113 RIOSTRA TIPO "RP" ENANO DE HORMIGON PERNOS DE ANCLAJE -0.3784672794435835 -0.3784672794435835 -0.3784672794435835 -14.21885540690486 REMATE DE CHAPA PRELACADA PLACA LC-14 UPN-180 PILAR PORTICO TRATAMIENTO SUPERFICIAL CON ACABADO EN RESINA SOLERA DE HORMIGON H-200 DOBLE MALLAZO 15X15cm (d6mm) -0.3784672794435835 -0.3784672794435835 CANALON DE CHAPA GALVANIZADA e=0.6mm 2UPN-100 A TOPE CUBIERTA DE CHAPA GALVANIZADA e=0.6mm CORREA ZF-175X2 CON EJION DEL MISMO ESPESOR CHAPA GALVANIZADA e=0,6mm REMATE DE CHAPA PRELACADA CHAPA PRELACADA PERFIL METALICO 120X60X5 -0.3784672794435835 SOLDALDO AL PORTICO CF-120X3

Language	Spanish
Drawing Type	Section
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials	Concrete
Measurement Units
Footprint Area
Building Features
