Manhole Box DWG Block for AutoCAD

Manhole Box DWG Block for AutoCAD

Manhole to rainwaters

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

section, Registration box type detail, unscaled, plant, Poor concrete base, Concrete cap with mesh, Screw with nut, Exp., Cm blocks, With the cells filled with, Concrete wall blasting, In place of minimum thickness, Indicated pvc tube, Rods, Welded, variable

Raw text data extracted from CAD file:

SECCION A-A DETALLE TIPO DE CAJA DE REGISTRO SIN ESCALA .10 PLANTA BASE DE CONCRETO POBRE 0.60 0.40 0.60 A .10 TAPA DE CONCRETO COM MALLA DE TORNILLO 9 mmd, CON TUERCA REPELLADO Y LUJADO BLOQUES DE 12x20x40 cm CON LAS CELDAS RELLENAS DE CONCRETO o PARED CHORREADA EN SITIO DE 10cm ESPESOR MINIMO TUBO DE PVC d INDICADO A VARILLAS #2 @ 0.10 m SOLDADA .10 VARIABLE .07

Language	Spanish
Drawing Type	Block
Category	Mechanical, Electrical & Plumbing (MEP)
Additional Screenshots
File Type	dwg
Materials	Concrete
Measurement Units
Footprint Area
Building Features
Tags	autocad, block, box, DWG, einrichtungen, facilities, gas, gesundheit, l'approvisionnement en eau, la sant, le gaz, machine room, manhole, maquinas, maschinenrauminstallations, provision, wasser bestimmung, water
