Pedestal DWG Block for AutoCAD

Pedestal DWG Block for AutoCAD

Pedestal and plaque

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

npt, scale:, sheet no., detail of concrete pedestal, scale, concrete pedestal for commemorative plaque, grill in, pedestal by its four faces, shoe of, stuffing packed in moistened layers, con column on its four faces, notes: the dimensions in meters of psi, tile of, concrete pedestal for commemorative plaque

Raw text data extracted from CAD file:

\A1;0.60 \A1;0.15 \A1;0.60 NPT = ±0.00 \A1;0.05 \A1;0.08 \A1;0.10 \A1;0.05 \A1;0.025 \A1;1.15 \A1;0.075 \A1;0.025 \A1;0.075 \A1;0.025 \A1;0.57 \A1;0.075 \A1;45° 1:10 01 DE 1 ESCALA: HOJA No. DETALLE DE PEDESTAL DE CONCRETO 5 5 5 ESCALA 1:10 PEDESTAL DE CONCRETO PARA PLACA CONMEMORATIVA PARRILLA DE No.3 @ 0.16 EN A/D 5 5 PEDESTAL DE 0.20x0.20m RECUBRIMEINTO=0.05m POR SUS CUATRO CARAS ZAPATA DE 0.60x0.60x0.15 RELLENO COMPACTADO EN CAPAS DE 0.15m HUMEDECIDAS 5 5 5 5 COLUMNA DE 0.15x0.15 CON 4#3 Y EST #2 @ 0.15m. RECUBRIMIENTO=0.0254m POR SUS CUATRO CARAS NOTAS: 1-TODAS LAS DIMENSIONES EN METROS 2-CONCRETO DE 2500 PSI (A LOS 28 DIAS) 0.075 5 0.075 5 5 LOSETA DE 0.57x0.85 #2 @ 0.15 A/D 5 PEDESTAL DE CONCRETO PARA PLACA CONMEMORATIVA 5

Language	Spanish
Drawing Type	Block
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials	Concrete
Measurement Units
Footprint Area
Building Features
Tags	autocad, béton armé, block, concrete, DWG, formwork, pedestal, reinforced concrete, schalung, stahlbeton
