Plan Retaining Wall DWG Plan for AutoCAD

Plan Retaining Wall DWG Plan for AutoCAD

Cortes – dimensions – specification

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

plant cover to avoid erosion, drainage network, wall of gravel concrete cyclopeo in proportion of concrete stone the maximum size of the stone used will be of, sidewalks, pvc perforated french drain

Raw text data extracted from CAD file:

1.00 0.50 1.50 0.30 0.35 1.0 0.5 1.5 0.3000000000001819 1 1 covertura vegetal para evitar erosion covertura vegetal para evitar erosion Canal pluvial conectado a red de drenaje Muro de graveda concreto ciclopeo en proporcion de 65% piedra y 35% concreto 3000 PSI, El tamaño maximo de la piedra a utilizar sera de 8" Banquetas 0.3478430944182946 Drenaje frances PVC 6" perforado
