Plano Sewer Base DWG Block for AutoCAD

Plano Sewer Base DWG Block for AutoCAD

Plano sewer official vignette.

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

bedroom, living room, dinning room, desk, C.i., Leap of c.i. C.i. Mts pvc, pending, Leap of c.i. C.i. Mts pvc, Mts pvc, Pvc, manifold, Sewerage plan, Broken jar, sector, commune, Paihuano, Regularization project, firms, Location, technical data, Notice of initiation, Feasibility certificate, start date, End date, scale

Raw text data extracted from CAD file:

Dormitorio Dormitorio Living Comedor Escritorio C.I. Nº2 C.I. Nº3 C.I. Nº4 C.I. Nº5 C.I. Nº1 Salto de C.I. Nº1 a C.i. Nº 2 h= 10 mts pvc 110 Pendiente Pendiente Salto de C.I. Nº2 a C.i. Nº 3 h= 5 mts pvc 110 L= 5 mts pvc 110 i=3% L= 8 mts pvc 110 i=3% pvc 40 A COLECTOR PLANO DE ALCANTARILLADO QUEBRADA LA JARILLA Sector Comuna PAIHUANO PROYECTO DE REGULARIZACION FIRMAS UBICACION DATOS TECNICOS Aviso de Iniciacion Nº______________ Certificado de Factibilidad Nº_________ Fecha de Inicio Fecha de Termino ESCALA 1:75

Language	Spanish
Drawing Type	Block
Category	Mechanical, Electrical & Plumbing (MEP)
