Pulley and hook

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

crane hook, acot: centimeters, esc:, note: for the thread as the chamfer of, insert cap for adjustment, average adjustment separation, last hole for sure, forged hook, key made of wire

Raw text data extracted from CAD file:

33 R20 R30 R35 R38 R19 11 5 2 10 3 12 17 25 R22 \U+220560 6 R16 38 R3 R3 R5 R2 R1,5 14 20 48 5 3 12 22 28 6 8 18 12 GANCHO PARA GRÚA Acot:Centimetros Esc: S/E 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 Nota:para repesentacion de la Rosca M12X1,tome como dRaiz=10 y el chaflan de 1x45º Inserto casquillo para ajuste d16 Separacion ajuste medio 0.5 d d d Agujero pasado para seguro d3.2 +0.05/0 Gancho Forjado Chaveta construida con alambre d1.6
