Register of drawer – Register key

Drawing labels, details, and other text information extracted from the CAD file (Translated from Portuguese):

cvrd, leaf:, rev .:, cvrd:, minerconsult:, Variable dimensions, scale, in centimeter except where indicated, grades, chrome placket, registration of in pvc.sd, welding pvc tube var. conf. project, adapter weldable short bag var. conf. project, quant., var., item, Praça., Items., drawer registration var. conf. project, description, ref. tiger or similar, abnt, Note

Raw text data extracted from CAD file:

CVRD FOLHA: REV.: N° CVRD: N° MINERCONSULT: 3-PARA ELEVAÇÕES E DIMENSÕES VARIAVEIS VER INDICAÇÃO EM PLANTA 1-DES. S/ ESCALA 2-COTAS EM CENTÍMETRO EXCETO ONDE INDICADO NOTAS 1 2 3 2 1 CANOPLA CROMADA REGISTRO DE GAVETA-INST. EM PVC.SD TUBO DE PVC SOLDAVEL (PVC.SD) Ø VAR. CONF. PROJETO ADAPTADOR SOLDÁVEL CURTO BOLSA E ROSCA (PVC) Ø VAR. CONF. PROJETO QUANT. 01 01 VAR. ITEM PÇ. PÇ. 3 UNID. m. 2 1 REGISTRO DE GAVETA Ø VAR. CONF. PROJETO DESCRIÇÃO REF. TIGRE OU SIMILAR NBR-5648 ABNT OBSERVAÇÃO

Language	Portuguese
Drawing Type	Block
Category	Mechanical, Electrical & Plumbing (MEP)
