Reinforced Concrete Slab – Detail DWG Detail for AutoCAD

Reinforced Concrete Slab – Detail DWG Detail for AutoCAD

Reinforced concrete slab – Detail – Flat Slab

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

flattening mortar, with mortar, concrete hollow seated, partition wall parapet, reinforced concrete, block partition wall, structural plans, hollow concrete seated with, mortar, proportion, proportion, proportion, brushed finish, reinforced concrete slab, mortar mortar, structural plans, tepetate filling, waterproofing, tezontle, with brick lid, reinforced concrete repison, dropper, structural plans, proportion, proportion of thickness, grout, brick, lock of, proportion to receive, mortar chamfer, mortar, specifications notes, roof filling., anger placed on the slab his goal is to endow, the roof with enough slopes for the easy, rapid runoff from rainwater., the following indications must be adjusted:, the filling should not allow settlements, caused by the consolidation of the material., will serve as the basis for receiving the mortar, to sand in the proportion indicated in, about the corresponding insert., Before carrying out the slabs, they must, be free of gravel any other, in the case of roof fills, the slopes are already established, downloads., materials:, The following materials will be used in the, Filling of fillings., tezontle: sera tezontle gravel with a, maximum hand of aggregate of, Ganicas sand., tepetate: will be a free bank of subjects, the use of land will not be allowed, product of excavations., bricklaying, stacked, roof filling, reinforced concrete slab, detail no.

Raw text data extracted from CAD file:

APLANADO DE MORTERO CON MORTERO DE CEMENTO-ARENA DE CONCRETO HUECO ASENTADO PRETIL DE TABIQUE O BLOCK CONCRETO ARMADO MURO DE TABIQUE O BLOCK DE (ver planos estructurales CONCRETO HUECO ASENTADO CON MORTERO DE CEMENTO-ARENA PROPORCION 1:4 DE CEMENTO-ARENA PROPORCION 1:4 correspondientes) PROPORCION 1:4 5mm. ACABADO ESCOBILLADO LOSA DE CONCRETO ARMADO CEMENTO-ARENA ENTORTADO DE MORTERO (ver planos estructurales correspondientes) RELLENO DE TEPETATE IMPERMEABILIZANTE O TEZONTLE 2.5x13x26cms. CON TAPA DE LADRILLO REPISON DE CONCRETO ARMADO GOTERO DE 3/4" correspondientes) (ver planos estructurales PROPORCION 1:4 PROPORCION 1:1:6 Y ESPESOR DE LECHADA DE CEMENTO-CAL-ARENA ENLADRILLADO, LADRILLO DE TRABE DE PROPORCION 1:6 PARA RECIBIR CHAFLAN DE MORTERO MORTERO DE CEMENTO-ARENA NOTAS DE ESPECIFICACIONES RELLENO EN AZOTEA. 1.- IRA COLOCADO SOBRE LA LOSA Y SU OBJETIVO ES DOTAR A LA AZOTEA DE PENDIENTES SUFICIENTES PARA EL FACIL Y RAPIDO ESCURRIMIENTO DE LAS AGUAS PLUVIALES. DEBERA AJUSTARSE A LAS INDICACIONES SIGUIENTES: 2.- EL RELLENO NO DEBERA PERMITIR ASENTAMIENTOS LOCA- LES PROVOCADOS POR LA CONSOLIDACION DEL MATERIAL. SERVIRA DE BASE PARA RECIBIR EL MORTERO DE CEMEN- TO ARENA EN LA PROPORCION INDICADA EN EL PROYEC- TO, SOBRE EL ENTORTADO CORRESPONDIENTE. 3.- ANTES DE EFECTUAR EL RELLENO, LAS LOSAS DEBERAN ESTAR LIBRES DE CIMBRA, CASCAJO O CUALQUIER OTRO MATERIAL; EN EL CASO DE RELLENOS DE AZOTEAS DEBE- RAN ESTAR YA ESTABLECIDAS LAS PENDIENTES HACIA LAS BAJADAS. 4.- MATERIALES: LOS SIGUIENTES MATERIALES SE EMPLEARAN EN LA FA- BRICACION DE RELLENOS. a).- TEZONTLE: SERA RIPIO DE TEZONTLE CON UN TA- MANO MAXIMO DE AGREGADO DE 2.5cm. GANICAS Y ARENA. b).- TEPETATE: SERA DE BANCO LIBRE DE MATERIAS OR- NO SE PERMITIRA EL USO DE CASCAJO, PIEDRA, TIERRA O PRODUCTO DE EXCAVACIONES. ENLADRILLADO RETACADO (PASTA CEMENTO-CAL 1:3) 5.- RELLENO EN AZOTEA 3. LOSA DE CONCRETO ARMADO DETALLE No. 3.2.

Language	Spanish
Drawing Type	Detail
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials	Concrete, Other
Measurement Units
Footprint Area
Building Features
Tags	autocad, concrete, dach, dalle, DETAIL, DWG, escadas, escaliers, flat, lajes, mezanino, mezzanine, platte, reinforced, reservoir, roof, slab, stair, telhado, toiture, treppe
