Reserve And Portuguese Roadway DWG Section for AutoCAD

Reserve And Portuguese Roadway DWG Section for AutoCAD

Section with technical specifications

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Superior Technical School of Architecture of Donostia San Sebastian, course, viviani vincenzo, building construction analysis, brick, plaster, crujia areada, vapor barrier, alcatifa, floor in tiles, thermal isolation, subsurface area layer, concrete, pinato, concrete, drain tube, reinforced concrete masonry, Earth, gravel, waterproof sheath, drainage protection, legend, viviani vincenzo, building construction analysis, Superior Technical School of Architecture of Donostia San Sebastian, course, foundation detail, esc, natural terrain, mild betonilha, portuguese calçada, Gravel layer for drainage, draining pipe, geotextile blanket, massame armed, marble stone of estremoz, door, compacted terrain, brick, foundation beam, betonilha, enrrocamento, waterproofing, massame

Raw text data extracted from CAD file:

ESCUELA TECNICA SUPERIOR DE ARQUITECTURA DE DONOSTIA - SAN SEBASTIAN 1:20 2000/2001 CURSO 9 1 2 3 4 5 6 7 8 15 14 13 12 11 10 VIVIANI VINCENZO ANALISIS CONSTRUCTIVO DE EDIFICIOS 18 17 16 Ladrillo Revoque Crujia areada Barrera a el vapor Alcatifa Suelo en azulejos Aislamiento termico Aislamiento termico Capa de areaciòn del subsuelo Hormigonado Pinato Concreto Tubo del drenaje Albanileria en hormigon armado Tierra Grava Vaina impermeable Protecciòn de drenaje LEYENDA 9 1 2 3 4 5 6 7 8 18 17 16 15 14 13 12 11 10 VIVIANI VINCENZO ANALISIS CONSTRUCTIVO DE EDIFICIOS ESCUELA TECNICA SUPERIOR DE ARQUITECTURA DE DONOSTIA - SAN SEBASTIAN 1:20 2000/2001 CURSO DETALLE DE FUNDACION ESC. 1:10 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 1 TERRENO NATURAL 2 BETONILHA LEVE 3 CALçADA PORTUGUESA 4 CAPA DE GRAVA PARA DRENAGE 5 TUBO DRENANTE 6 MANTA GEOTEXTIL 12 MASSAME ARMADO 11 PIEDRA MARMOL DE ESTREMOZ 10 PUERTA 9 TERRENO COMPACTADO 8 LADRILLO 0,11cm 7 VIGA DE FUNDACION 15 BETONILHA 16 ENRROCAMENTO 13 IMPERMEABILIZACION 14 MASSAME

Language	Spanish
Drawing Type	Section
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials	Concrete, Masonry
Measurement Units
Footprint Area
Building Features
Tags	assoalho, autocad, deck, DWG, fliese, fließestrich, floating floor, floor, flooring, fußboden, holzfußboden, piso, plancher, plancher flottant, portuguese, reserve, section, specifications, technical, tile
