Roof – Shump Collision

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

tile color waterproofing paint, ceramic scraper, gripping mortar, ceramic shunt piece of ventilation, waterproofing membrane e.p.d.m., thermal isolation, Solera anchor bar fixed every mm. with screws, lap adhesive, sealant sealant, waterproofing membrane e.p.d.m., lap adhesive, polystyrene, sealant sealant

Raw text data extracted from CAD file:

\A1;27mm \A1;>10 mm PINTURA IMPERMEABILIZANTE COLOR TEJA RASILLA CERÁMICA MORTERO DE AGARRE PIEZA CERÁMICA SHUNT DE VENTILACIÓN MEMBRANA IMPERMEABILIZANTE E.P.D.M. AISLAMIENTO TÉRMICO >10 mm BARRA DE ANCLAJE SOLERA FIJADA CADA 300 mm. CON TORNILLOS ADHESIVO DE SOLAPO SELLANTE DE SOLAPO MEMBRANA IMPERMEABILIZANTE E.P.D.M. ADHESIVO DE SOLAPO POLIESTIRENO EXPANDIDO; e=2cm SELLANTE DE SOLAPO 27mm

Language	Spanish
Drawing Type	Block
Category	Construction Details & Systems
