Roofing DWG Block for AutoCAD

Roofing DWG Block for AutoCAD

Different types of roofing.

Drawing labels, details, and other text information extracted from the CAD file (Translated from Portuguese):

ridge height, maximum spacing between slats:, maximum spacing between rails:, maximum spacing between Tuesdays:, maximum spacing between treasures:, grades:, ridge height, go from, clapboard, pendural, ridge, dog lock, rafter, dip, board, counterfeit, Tuesday, line, flexal, ass, stirrup, go from, leg, go from

Raw text data extracted from CAD file:

Altura da Cumeeira 4- ESPAÇAMENTO MÁXIMO ENTRE RIPAS: 0,30m. 3- ESPAÇAMENTO MÁXIMO ENTRE CAIBROS: 0,50m; 2- ESPAÇAMENTO MÁXIMO ENTRE TERÇAS: 3,00m; 1- ESPAÇAMENTO MÁXIMO ENTRE TESORUAS: 4,00m; NOTAS: Altura da Cumeeira Vão de 7,50m Ripa (4x2cm) Pendural (12x8cm) Cumeeira (12x8cm) Travamento do Cachorro (6x6cm) Caibro (7x4cm) Chapuz (12x8x25cm) Tábua (Guarda-pó) Cachorro(7x4cm) Contrafeito (7x4cm) Terça (12x8cm) Linha (12x8cm) Flexal (12x8cm) Asna (8x8cm) Estribo (Ferro) Vão de 7,50cm Perna (12x8cm) Vão de 10,00m Vão de 10,00m
