Roof on metallic joists and isolating between beams

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Upper forged, Rigid insulation, Plaster plaster mortar, Placner coatings, Light profile, Joists ipn ipe, Forged placner, Compression layer, Max. Cms., With insulation in tunnel, Solution placner, Cover over metal joists

Raw text data extracted from CAD file:

FORJADO SUPERIOR AISLAMIENTO RIGIDO ENLUCIDO DE YESO O MORTERO PLACNER REVESTIMIENTOS PERFIL LIGERO U - Z VIGUETAS IPN - IPE PLACNER FORJADOS CAPA DE COMPRESION ( 3 cms.) Max. 90 cms. Max. 90 cms. CON CIELO-RASO Y AISLAMIENTO EN ENTREVIGADO SOLUCION PLACNER CM-5.- CUBIERTA SOBRE VIGUETAS METALICAS
