Sealed DWG Detail for AutoCAD

Sealed detail of joint type Grayloc

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

rib, clamp surface, in the joint the internal pressure acts against the surface of the lips of the grayloc seal ring reinforcing the seal. in the joint the pressure acts directly on the faces of the flanges forcing them to separate., low behavior oresion of a grayloc connection a flange, The rib of the seal ring is positioned between the faces of the hub. The lips of the seal ring adjust the internal surface of the hub in an interference fit by causing its bending to obtain a metal metal seal., as it is the sealing of a grayloc connection, clamp, hub, lip seal ring, seal ring

Raw text data extracted from CAD file:

COSTILLA SUPERFICIE DE LA ABRAZADERA EN LA JUNTA GRAYLOC, LA PRESION INTERNA ACTUA CONTRA LA SUPERFICIE DE LOS LABIOS DEL ANILLLO DE SELLO GRAYLOC REFORZANDO EL SELLO. EN LA JUNTA BRIDADA, LA PRESION ACTUA DIRECTAMENTE EN LAS CARAS DE LAS BRIDAS FORZANDOLAS A SEPARARSE. COMPORTAMIENTO BAJO ORESION DE UNA CONEXION GRAYLOC Y UNA BRIDA LA COSTILLA DEL ANILLO DE SELLO SE POSICIONA ENTRE LAS CARAS DEL HUB. LOS LABIOS DEL ANILLO DE SELLO SE AJUSTAN A LA SUPERFICIE INTERNA DEL HUB EN UN AJUSTE DE INTERFERENCIA OCACIONANDO SU FLEXION PARA OBTENER UN SELLO METAL A METAL. COMO ES EL SELLADO DE UNA CONEXION GRAYLOC ABRAZADERA HUB LABIO DEL ANILLO DE SELLO ANILLO DE SELLO

Language	Spanish
Drawing Type	Detail
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials
Measurement Units
Footprint Area
Building Features
Tags	autocad, dach, dalle, DETAIL, DWG, escadas, escaliers, joint, lajes, mezanino, mezzanine, platte, reservoir, roof, slab, stair, telhado, toiture, treppe, type
