Section Wooden Auditorium DWG Section for AutoCAD

Section Wooden Auditorium DWG Section for AutoCAD

Constructive section – Technical specifications –

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

reinforced concrete beam, double galvanized steel beam, isopac plate with gravure of mm, roll blind in PVC with polyurethane core, domus gewiss halogen projector, triple tempered glass, premarco raulí, overlap partition in oregon pine, cogent chain, alusatermic sheet, plaque wood chipboard, Insulation plate mm, internit plate, radier cm, sobrelosa cm, moisture barrier: polyethylene sheet mm, cm gravel layer, cm sand layer, compacted terrain, reinforced concrete roof, adhesive mortar for stone cladding, pine ribbon, lining galvanized steel mm, diagonal pine encamizado, costanera galvanized steel profile, felt of bs., gravel asphalt tile, scantillon auditorium esc, high traffic floor cover, slate stone slate sand, anodized aluminum frame, inferior solera in pino insigne, galvanized steel cutter in mm, overlap partition in oregon pine, water channel rain steel galvanized mm, wedges pine insigne, downstream galvanized steel mm, top galvanized water drop pipe mm, galvanized water drop pipe mm

Raw text data extracted from CAD file:

Viga Hormigón Armado Viga Acero Galvanizado Doble " T" Placa ISOPAC con gravillado de 50 mm Rollo Persiana en PVC con alma de Poliuretano Proyector Halógeno DOMUS GEWISS Vidrio Templado Triple Premarco Raulí Traslapo Tabique en Pino Oregón 1' x 8' Cadeneta 3' x 3' Coigüe Lámina de Alusatermic Placa Madera aglomerada enchapada Placa de Aislapol 50 mm Placa de Internit Radier de 10 cm Sobrelosa 5 cm Barrera Humedad :Lámina de Polietileno 0.3 mm Capa de Ripio de 20 cm Capa de Arena de 10 cm Terreno Compactado Enfierraduras Antetecho Hormigón Mortero de pega para revestimiento de Piedra Listón Pino 2' x 2' Forro Acero Galvanizado de 0.5 mm Encamizado de Pino Diagonal 4' x 1' Costanera Perfil " C " Acero Galvanizado Fieltro de 12 l bs. Teja Asfáltica Gravillada ESCANTILLON AUDITORIO ESC . 1 : 5 Cubrepiso Alto Tráfico Chapa de Piedra Pizarra Arena Marco de Aluminio Anodizado Solera Inferior en Pino Insigne Cortagotera en Acero Galvanizado de 0.3 mm Traslapo Tabique en Pino Oregón 1' x 8' Canal Agua Lluvia Acero Galvanizado 0.3 mm Cuñas Pino Insigne Bajada Aguas Acero Galvanizado de 0.3 mm Remate Tubo bajada de agua Galvanizado 0.3 mm Tubo bajada de agua Galvanizado 0.3 mm

Language	Spanish
Drawing Type	Section
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials	Aluminum, Concrete, Glass, Steel, Wood
Measurement Units
Footprint Area
Building Features
Tags	Auditorium, autocad, construction details section, constructive, cut construction details, DWG, section, specifications, technical, wooden
