Constructive details

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

comes from the kitchen, septic outlet, comes from the kitchen, ring, concrete cover, plant, cut, grease trap, esc, output percolation well, your B., comes from the fat trap, concrete cover, gas exhauster, clayey layer, mud, inspection box, gravel, reinforcement ring, top, concrete cover, gravel, brick, esc, septic tank, plant, cut, percolation well, esc, cut, plant

Raw text data extracted from CAD file:

0,60 0,05 0,50 0,05 0,05 0,50 0,05 0,60 0,15 0,30 0,15 1,40 0,40 1,00 0,50 0,05 0,50 1,30 0,15 1,00 0,15 2,30 0,15 2,00 0,15 0,45 2,65 0,10 2,40 0,15 0,15 0,24 0,90 0,24 0,15 1,68 1,68 0,15 0,24 0,24 0,15 0,90 0,40 2,00 5 5 5 5 5 5 5 5 VIENE DE LA COCINA SALIDA A TQUE SÉPTICO SALIDA A TQUE SÉPTICO VIENE DE LA COCINA 5 5 5 ARGOLLA TAPA DE CONCRETO Ø 4" A A PLANTA CORTE A-A TRAMPA DE GRASA ESC 1/25 SALIDA A POZO DE PERCOLACION TUB. d 4" Ø 4" VIENE DE LA TRAMPA DE GRASAS TAPA DE CONCRETO TAPA DE CONCRETO 0.60 X 0.60 0.60 X 0.60 SALIDA DE GASES 5 5 5 5 5 5 CAPA ARCILLOSA FANGO 5 5 5 5 5 5 5 5 A A 5 CAJA DE INSPECCION 12" X 24" CAJA DE INSPECCION 12" X 24" GRAVA d 3/4" a 1½" ANILLO DE REFUERZO 2d 3/8" d ¼" S TAPA 0.20 x 0.20 TAPA DE CONCRETO 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 GRAVA d 3/4" a 1½" LADRILLO KING-KONG 5 5 ESC 1/25 POZO SÉPTICO PLANTA CORTE A-A POZO DE PERCOLACION ESC 1/25 CORTE A-A PLANTA A A
