Single-Story Residential Floor Plan with Two-Bedroom Layout

This floor plan depicts a compact single-story residence featuring two identical bedrooms measuring 10’0″ × 18’5″ each. This layout includes multiple door types with standard 3’×7′ main doors (D) and 2’6″×7′ interior doors (D1). Window configurations vary with three types: W1 (5’×4′), W2 (4’×4′), and a smaller 3’×4′ variant. The design incorporates ventilation elements (V) measuring 3’×1’6″ at key locations. The overall dimensions include widths of 8’7″, 10’0″, 8’0″, and 16’0″ across different sections, with depth measurements of 12’8″ and 4’6″. The circulation pattern utilizes a central corridor design that efficiently connects all rooms while maximizing usable floor space. Interior wall placement creates well-proportioned rooms with appropriate clearances for residential occupancy. The 9″ and 4.5″ dimensions likely indicate wall thicknesses or offsets; these practical considerations ensure proper structural integrity while maintaining functional interior spaces.
