Tanquilla Circular Recess DWG Block for AutoCAD

Tanquilla Circular Recess DWG Block for AutoCAD

Tanquilla Circular Recess (Cachimbo)

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Concrete, Pvc, Slope collector min., Pvc, Of pvc registration, Minimum, Pvc, Yee pvc, Pvc, Home in pvc, side, plant, detail

Raw text data extracted from CAD file:

\A1;BASE DE CONCRETO \A1;CODO 45° d 100mm \A1;TUBERIA PVC d 100mm \A1;YEE PVC d 160x100mm \A1;CODO 90° d 160mm \A1;AL COLECTOR PENDIENTE MIN. 2% \A1;TUBERIA PVC d 160mm \A1;TAPON DE REGISTRO PVC d 160mm \A1;PROFUNDIDAD MINIMA = 0.90M \A1;BROCAL \A1;PAVIMENTO \A1;ACERA \A1;TUBERIA PVC d 160mm \A1;SILLA YEE PVC d 160x100mm \A1;CODO 45° d 100mm \A1;COLECTOR PVC d 200mm \A1;TUBERIA PVC d 160mm \A1;\C7;EMPOTRAMIENTO DOMICILIARIO EN PVC \A1;VISTA LATERAL \A1;VISTA PLANTA \A1; DETALLE 1 (CACHIMBO) \A1; DETALLE 2 (COLECTOR PRINCIPAL)

Language	Spanish
Drawing Type	Block
Category	Mechanical, Electrical & Plumbing (MEP)
Additional Screenshots
File Type	dwg
Materials	Concrete
