Three-Story Residential house Plan with Sections and Elevations

**Comprehensive architectural drawing set for a modern three-story residence** with complete floor plans, sections, and elevations at 1:50 scale. The design features:

– **Floor Distribution:**
* First Floor: Kitchen, dining room, living room, car port, bathroom, and courtyard
* Second Floor: Multiple bedrooms (including master bedroom), bathrooms, study room, and family room
* Roof/Third Floor: Service area and terrace

– **Key Dimensions:**
Various room measurements are indicated, with typical room spans of 2.45m-3.60m and hallway widths of approximately 1.00m-1.20m. The floor-to-floor height is 2.70m (NPT+0.00 to NPT+2.85 to NPT+5.55).

– **Architectural Features:**
Includes interior courtyards, balcony, multiple bathrooms, laundry area, built-in furniture, and an elevated water tank. The exterior features pastel brick finishing.

– **Technical Details:**
Multiple door types (P1-P5) and window variations (V1-V10) are specified. The drawing includes section cuts (A-A, B-B, C-C) and a front elevation that clearly illustrate the vertical relationships between spaces.

The residence incorporates an efficient layout with good natural ventilation through strategic window placement and open courtyard areas. The design emphasizes both functionality and aesthetic appeal with designated family spaces and private zones.
