Train Download DWG Block for AutoCAD

Train Download DWG Block for AutoCAD

Exploded View of a train for a Deep Pit download

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

The beach resettlement colony, To the raised tank, venting, Discharge train, Concrete dock, Flange elbow, Welded reel, Manometer of glycerine, Pressure relief valve, flowmeter, Concrete dock, check valve, Flared tee, gate valve, filter, Galvanized tube with flange

Raw text data extracted from CAD file:

1.00 M 1.20 M 3.00 M 3.00 M 20 19 18 17 16 14 15 13 A LA COLONIA REACOMODO PLAYA DE MONO\Ftxt.shx|c0; 4" 5 3.00 M 27 AL TANQUE ELEVADO 4" 3" 4" DESFOGUE TREN DE DESCARGA DE 4" 1.00 M 1.20 M 3.00 M ATRAQUE DE CONCRETO 4" 3.00 M 1 2 3 4 5 2 7 8 9 9 9 11 10 6 6 1 CODO DE 90° CON BRIDA 2 CARRETE BRIDADO 3 MANOMETRO DE GLICERINA 4 VALVULA ALIVIADORA DE PRESION 5 MEDIDOR DE FLUJO 6 ATRAQUE DE CONCRETO 7 VALVULA CHECK 8 TEE BRIDADA 9 VALVULA DE COMPUERTA 10 FILTRO 11 TUBO GALVANIZADO CON BRIDA

Language	Spanish
Drawing Type	Block
Category	Mechanical, Electrical & Plumbing (MEP)
Additional Screenshots
File Type	dwg
Materials	Concrete
Measurement Units
Footprint Area
Building Features	Car Parking Lot
Tags	autocad, block, deep, Download, DWG, einrichtungen, elbow, exploded, facilities, gas, gesundheit, l'approvisionnement en eau, la sant, le gaz, machine room, maquinas, maschinenrauminstallations, pit, provision, train, valve, View, wasser bestimmung, water
