Valve DWG Block for AutoCAD

Valve DWG Block for AutoCAD

CAMERA MACRO METER

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Cap according to detail, stucco, Gravel, Terminal bg, Support machon, Terminal bb fe fdo, Union gibault, Pool of, Reinforced concrete, Terminal bb fe fdo, Pvc tube, Detail valve for future macro meter, Terminal bb fe fdo, terminal, Elastomeric valve bb, Esc., Faith galv., stucco, Stairs, terminal, Terminal bb fe. Fdo., Cap according to detail, N.t.n., Simple mesh inf.

Raw text data extracted from CAD file:

0.09 0.2 0.3 0.4 0.5 0.8 14 60 20 TAPA SEGÙN DETALLE ESTUCO e=2cm RIPIO TERMINAL BG TERMINAL BG D:100mm.;L=30cm. MACHON DE APOYO 170 KG CEM./M3 TERMINAL BB Fe Fdo D:100mm.;L=35cm. D:100mm.;L=30cm. UNION GIBAULT D:100mm.;L=15cm. PILETA DE 4" DE 340 KG.CEM/M3 CONCRETO ARMADO TERMINAL BB Fe Fdo D:100mm.;L=35cm. 1m3 D=110mm. TUBO PVC DETALLE VALVULA C/CAMARA PARA FUTURO MACRO MEDIDOR D:100mm.;L=60cm. TERMINAL BB Fe Fdo TERMINAL B-PVC D:110x100mm. L=30cm. 0.20 0.07 VALVULA ELASTOMERICA BB D:100mm. ; L=30cm. i=0.5% 2.35 ESC. 1:20 FE GALV. 1.00 H ESTUCO e=2cm. ESCALINES TERMINAL B-PVC D:100x110mm. TERMINAL BB Fe. Fdo. D:100mm.;L=60cm. D L=30cm. 14 60 20 TAPA SEGUN DETALLE N.T.N. d 16 A 10 MALLA SIMPLE INF.

Language	Spanish
Drawing Type	Block
Category	Water Sewage & Electricity Infrastructure
Additional Screenshots
File Type	dwg
Materials	Concrete
Measurement Units
Footprint Area
Building Features	Pool
Tags	autocad, block, camera, distribution, DWG, fornecimento de água, kläranlage, l'approvisionnement en eau, meter, supply, treatment plant, valve, wasserversorgung, water, water installation
