Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Terminal block, Naked, Copper rod, Vegetable soil, With thorgel, Ground well detail, Cu tw, Ground, Terminal block for, Terminal block, Naked, Copper rod, Vegetable soil, With thorgel, Ground well detail, Cu tw, Ground, Terminal block for

Raw text data extracted from CAD file:

\A1;0.80 BORNERA Cu DESNUDO 35 mm2. VARILLA DE COBRE TIERRA VEGETAL CON THORGEL 2.00m x 5/8"d \A1;2.40 DETALLE DE POZO DE TIERRA Cu TW 35 mm2. \A1;0.30 \A1;0.05 \A1;0.05 S/E PUESTA A TIERRA BORNERA PARA \A1;0.60 \A1;0.20 BORNERA Cu DESNUDO 35 mm2. VARILLA DE COBRE TIERRA VEGETAL CON THORGEL 2.00m x 3/4"d DETALLE DE POZO DE TIERRA Cu TW 35 mm2. \A1;0.30 \A1;0.05 \A1;0.05 S/E PUESTA A TIERRA BORNERA PARA 0.40 \A1;0.20 1.20 0.80

Language	Spanish
Drawing Type	Detail
Category	Mechanical, Electrical & Plumbing (MEP)
