Wooden Eaves DWG Block for AutoCAD

Wooden Eaves DWG Block for AutoCAD

Eaves with view gutteradjusted by wooden wedge

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Cover with slats, Cabios, Embossed felt, Suspension bearing. Installation level, Eave with canalon seen, Adjusted by a wooden wedge, With drop, Sheath, Ggf irons, vapor barrier, Insulation between parecillos, Additional insulation under parecillos, Plastic fiberglass foam, Max of total effectiveness, Large format with stop, Thermal

Raw text data extracted from CAD file:

- CUBRICION CON LISTONES - CABIOS - FIELTRO EMBETUMINADO - COJINETE SUSTENT. / NIVEL INSTALAC. ALERO CON CANALON VISTO AJUSTADO POR UNA CUÑA DE MADERA CON GOTERON - CAPA HERMETICA DE PLACAS DE SOLIDO, GGF PLANCHAS - BARRERA DE VAPOR - AISLANTE ENTRE PARECILLOS - AISLANTE ADICIONAL DEBAJO DE PARECILLOS DE ESPUMA PLASTICA DE FIBRA DE VIDRIO MAX 20% DEL TOTAL DE EFECTIVIDAD FORMATO GRANDE CON TOPE TERMICAS
