Bridge Crane Wheel DWG Block for AutoCAD

Bridge Crane Wheel DWG Block for AutoCAD

WHEEL FOR CRANE BRIDGE CRANE OF 40 tons. MADE OF STEEL SAE 4140, WITH CENTRAL AXIS MADE OF STEEL SAE 1045.

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

fixing sleeve

Raw text data extracted from CAD file:

d240 d280 d351 41 Manguito de fijación d240 d280 d351 41 Manguito de Fijacion para Rodamiento: 240x540x165 Rodamiento; 22352 cck/w33 Manguito; OH 2352 h d50 d120 22 50 d250 d400 d17 80 100 140 5 5 5 5 5 5 d17 5 5 5 \A1;20 \A1;38 \A1;Ø10 \A1;Ø20 \A1;Ø50 \A1;Ø100 \A1;8 \A1;4 \A1;20 \A1;10 \A1;0.10 \A1;Ø24mm Rueda de Acero SAE 4140 Para, Puente Grua de 40 Tons 20 38 Ø10 Ø20 Ø50 Ø100 8 4 20 10 0.10 Ø24mm

Language	Spanish
Drawing Type	Block
Category	Industrial
Additional Screenshots
File Type	dwg
Materials	Steel, Other
Measurement Units	Metric
