Construction Details of Castles (reinforcements for masonry walls) Reinforced Concrete (reinforced concrete) in different sections. Includes indicators Reinforcing Steel, Concrete type (concrete) and Annotations. Details are scaled to 1:20

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

kind, concrete brick wall type brick in view of in cm dimensions, concrete in castles, electro-welded castle brand armex, kind, details of castles type, scale:, electro-welded castle brand armex

Raw text data extracted from CAD file:

1 \A1;0.10 \A1;0.10 \A1;0.15 \A1;0.10 \A1;0.10 \A1;0.15 \A1;0.15 \A1;0.10 \A1;0.10 \A1;0.20 \A1;0.15 \A1;0.10 \A1;0.10 \A1;0.15 \A1;0.15 \A1;0.15 TIPO K-1 TIPO K-2 TIPO K-3 Muro de ladrillo de concreto (revisar tipo de ladrillo en vistas en planta) de medidas 7 x 13 x 26 cm 1 2 4 Concreto en castillos f´c= 250 kg/cm² Castillo electrosoldado marca armex 15-20-4 fy=6000 kg/cm² (4d#2-Ecal8) 5 5 5 5 3 2 1 1 5 5 5 5 5 5 5 5 3 3 1 1 1 2 TIPO K-4 5 5 5 4 1 2 5 1 6 DETALLES DE CASTILLOS TIPO ESCALA: 1:20 3 Castillo electrosoldado marca armex 15-15-4 fy=6000 kg/cm² (4d#2-Ecal8) 2

Language	Spanish
Drawing Type	Section
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials	Concrete, Masonry, Steel
Measurement Units
Footprint Area
Building Features
Tags	autocad, béton armé, castles, concrete, construction, details, DWG, formwork, masonry, reinforced, reinforced concrete, reinforcements, schalung, section, stahlbeton, walls
