Constructive details – Inclined roof – Interior isolation

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Sloped roofs, Spanish glassware s.a., Isolation, wrought, Continuous ceiling, By the interior, Insulated inclined roofs, Fig., Felt isover ibr type, Sheet of plasterboard, Thickness mm, Expansion pad, Threaded rod, Master suspension fork, Distance teachers between, Axes, Waterproofing, Mortar layer of cm, Concrete ceramic tile

Raw text data extracted from CAD file:

2. CUBIERTAS INCLINADAS CRISTALERIA ESPAÑOLA S.A. Division Aislamiento 1 - FORJADO 1 - TECHO CONTINUO - POR EL INTERIOR CUBIERTAS INCLINADAS CON AISLAMIENTO 4. 4 2 3 5 6 7 8 9 10 FIG. 1 2 - FIELTRO " ISOVER " TIPO IBR 3 - PLACA DE CARTON - YESO LAMINADO DE ESPESOR 13-15 mm 4 - TACO DE EXPANSION 5 - VARILLA ROSCADA M6 6 - HORQUILLA SUSPENSION MAESTRAS 7 - MAESTRAS DISTANCIADAS A 600 mm ENTRE EJES 8 - IMPERMEABILIZACION 9 - CAPA DE MORTERO DE 2 cm 10 - TEJA CERAMICA O DE HORMIGON

Language	Spanish
Drawing Type	Detail
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials	Concrete, Glass
Measurement Units
Footprint Area
Building Features	Car Parking Lot
Tags	autocad, barn, constructive, cover, dach, DETAIL, details, DWG, hangar, inclined, interior, isolation, lagerschuppen, roof, shed, structure, terrasse, toit
