Constructive Section Building With Under Ground ,2 Plants And Terrace DWG Section for AutoCAD

Constructive Section Building With Under Ground ,2 Plants And Terrace DWG Section for AutoCAD

Constructive section building with underground, two plants and terrace – Details

Drawing labels, details, and other text information extracted from the CAD file (Translated from Galician):

Arab tile, Layer of compression, Asphalt waterproofing., Mashed raspberry, Walnuts in walnuts taken with cement mortar, Steam barrier, Threaded birch with cement mortar, Garnished plaster plaster, Cross-sectional forging, Garnished plaster plaster, Cross-sectional forging, Garnished plaster plaster, Cross-sectional forging, Garnished plaster plaster, Cross-sectional forging, Garnished plaster plaster, Cross-sectional forging, Garnished plaster plaster, Rigid thermal insulation machined type roofmate silillary, Cell concrete, Asphaltic cloth with continuous polyester armor, Dosing mortar, Mortar for grip of dosage, Ceramic tile flooring, Double hollow brick tabicon taken with mortar, Air chamber, He quoted double hollow brick taken with mortar, Monolayer type coating, Formation of zabaleta with baldosin catalan, Alfalation of artificial stone, Soleria marble standard dimensions, Impact similar to fonpex impact acoustic insulation, Sand chamber for leveling, Protective grip mortar, Soleria marble standard dimensions, Impact similar to fonpex impact acoustic insulation, Sand chamber for leveling, Protective grip mortar, Slab of reinforced concrete, Helicopter termination, Plastered with cement mortar, Monolayer coating with projected arid, Thermal insulation with semir plates. Fiberglass, Quote double hollow brick, Garnished plaster plaster, Double hollow brick tabicon, Impact similar to fonpex impact acoustic insulation, Asphaltic cloth with continuous polyester armor, Protective grip mortar, Mortar for formation of earrings, Rustic stone extruded sandstone, Floor level, Semisotano plant, Plant, Impact similar to fonpex impact acoustic insulation, Soleria marble standard dimensions, Garnished plaster plaster, Cross-sectional forging, Protective grip mortar, Sand chamber for leveling, Turret plant

Raw text data extracted from CAD file:

TEJA ARABE CAPA DE COMPRESION IMPERMEABILIZANTE ASFALTICO. RASILLA MACHIEMBRADA TABICONES EN AVISPERO TOMADOS CON MORTERO DE CEMENTO 1:6 BARRERA DE VAPOR -0.60 ENFOSCADO Y FRATASADO CON MORTERO DE CEMENTO 1:6 GUARNECIDO Y ENLUCIDO DE YESO FORJADO RETICULAR FORJADO RETICULAR GUARNECIDO Y ENLUCIDO DE YESO FORJADO RETICULAR GUARNECIDO Y ENLUCIDO DE YESO FORJADO RETICULAR GUARNECIDO Y ENLUCIDO DE YESO FORJADO RETICULAR GUARNECIDO Y ENLUCIDO DE YESO FORJADO RETICULAR GUARNECIDO Y ENLUCIDO DE YESO AISLAMIENTO TERMICO RIGIDO MACHIEMBRADO TIPO ROOFMATE O SILILAR e=40mm. HORMIGON CELULAR D=600K Kg/m3, e.min=15cm. TELA ASFALTICA CON ARMADURA CONTINUA DE POLIESTER (1Kg./m2) MORTERO DE PROTECCION, DOSIFICACION 1:6, e.min=2cm. MORTERO PARA AGARRE DE SOLERIA, DOSIFICACION 1:8, e.min=2cm. SOLERIA DE BALDOSIN CERAMICO TABICON DE LADRILLO HUECO DOBLE TOMADO CON MORTERO 1:6 CAMARA DE AIRE CITARA DE LADRILLO HUECO DOBLE TOMADO CON MORTERO 1:6 RECUBRIMIENTO PETREO, TIPO MONOCAPA FORMACION DE ZABALETA CON BALDOSIN CATALAN ALFEIZAR DE PIEDRA ARTIFICIAL SOLERIA DE MARMOL NACIONAL, DIMENSIONES ESTANDAR AISLANTE ACUSTICO AL IMPACTO TIPO FONPEX O SIMILAT e=2mm. CAMARA DE ARENA PARA NIVELACION e.m.=3cm. MORTERO DE AGARRE Y PROTECCION 1:6 SOLERIA DE MARMOL NACIONAL, DIMENSIONES ESTANDAR AISLANTE ACUSTICO AL IMPACTO TIPO FONPEX O SIMILAT e=2mm. CAMARA DE ARENA PARA NIVELACION e.m.=3cm. MORTERO DE AGARRE Y PROTECCION 1:6 LOSA DE HORMIGON ARMADO H-200 e=80cm.HIDROFUGADO TERMINACION A HELICOPTERO ENFOSCADO CON MORTERO DE CEMENTO M-40 REVESTIMIENTO MONOCAPA CON ARIDO PROYECTADO AISLAMIENTO TERMICO CON PLANCHAS SEMIR. FIBRA DE VIDRIO CITARA DE LADRILLO HUECO DOBLE GUARNECIDO Y ENLUCIDO DE YESO TABICON DE LADRILLO HUECO DOBLE AISLANTE ACUSTICO AL IMPACTO TIPO FONPEX O SIMILAT e=2mm. TELA ASFALTICA CON ARMADURA CONTINUA DE POLIESTER (1Kg./m2) MORTERO DE AGARRE Y PROTECCION 1:6 MORTERO PARA FORMACION DE PENDIENTES P=1% SOLERIA DE GRES EXTRUSIONADO RUSTICO +16.50 +13.00 +7.00 +0.80 0.00 -3.20 -6.00 PLANTA NIVEL 4 PLANTA NIVEL 2 PLANTA NIVEL 1 PLANTA SEMISOTANO PLANTA SNIVEL3 +7.00 AISLANTE ACUSTICO AL IMPACTO TIPO FONPEX O SIMILAT e=2mm. SOLERIA DE MARMOL NACIONAL, DIMENSIONES ESTANDAR GUARNECIDO Y ENLUCIDO DE YESO FORJADO RETICULAR MORTERO DE AGARRE Y PROTECCION 1:6 CAMARA DE ARENA PARA NIVELACION e.m.=3cm. PLANTA DE TORRETA

Language	N/A
Drawing Type	Section
Category	Construction Details & Systems
Additional Screenshots	Missing Attachment
File Type	dwg
Materials	Concrete, Glass
Measurement Units
Footprint Area
Building Features	Car Parking Lot
Tags	autocad, building, construction details section, constructive, cut construction details, details, DWG, ground, plants, section, terrace, underground
