Constructive Section Childcare DWG Section for AutoCAD

Constructive Section Childcare DWG Section for AutoCAD

Section is made from two intersecting curves and ramps are anchored to a supporting wall; equally the cover having tensioners and supports a thin concrete slab.

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

concrete slab, plastered mm wall, concrete slab, glass partition mm, silicone, shoe taco, masked, compacted fill, stone ball, polyethylene, profile, waterproofing, quilt, triplex mm, chanul lacquered wood plank, construction section esc, gualaquiza street, psychology, pediatrics, years, early stimulation, ramp, constructive section, cortagotas, concrete cover, profile type, profile type, structural wall mm, metal deck, metal acrylic holder, hex head screw, acrylic sheet, anchor bolt, articulation profiles, tensioner mm, construction section esc, gualaquiza street, psychology, pediatrics, years, early stimulation, ramp, constructive section, andrea n. blond j., land paid, natural soil, hiltty pin, Anchor plate, lower armor zapata, cleaning concrete, hiltty pin, leveling mortar, metal column, construction section esc, stone ball, simple concrete, longitudinal reinforcement, lintel, fences cm, beam profile type, welding of, welding cross beams column, reinforced concrete wall, hex head screw, metal acrylic holder, acrylic sheet, reinforcement cm, acrylic sheet, metal deck, bolts, mm cm, electrowelded mesh cm, concrete slab seen

Raw text data extracted from CAD file:

GRADA DE HORMIGÓN e= 210 kg/cm2 MURO 80 MM + ENLUCIDO GRADA DE HORMIGÓN e= 210 kg/cm2 MAMPARA DE VIDRIO 4 MM SILICÓN CALZA O TACO MASILLADO RELLENO COMPACTADO PIEDRA BOLA POLIETILENO PERFIL I IMPERMEABILIZANTE CUARTÓN (40 X 40 MM) TRIPLEX 12 MM TABLÓN DE MADERA LACADO CHANUL (250 mm) \W5.25895; SECCIÓN CONSTRUCTIVA \W8.89943; esc 1:25 Calle Gualaquiza N -1.50 N -1.20 N -3.50 N -1.20 N -2.00 N -2.00 Psicología Pediatría 2 - 3 años Estimulación Temprana Estimulación Temprana 2 Rampa 5% Rampa 5% Rampa 5% N +-0.00 N +0.10 N -0.44 N -0.98 N -1.50 SECCIÓN CONSTRUCTIVA CORTAGOTAS CUBIERTA DE HORMIGÓN e= 180 kg/cm2 N - 3.50 N - 0.27 PERFIL TIPO I e=6mm 15 mm @250mm PERFIL TIPO I e=6mm @900mm MURO ESTRUCTURAL e=400 mm DECK METÁLICO (70mm) N +2.43 SOPORTE METÁLICO PARA ACRÍLICO e=6mm TORNILLO CABEZA HEXAGONAL PLANCHA DE ACRÍLICO 1.20 * 1.00 m PERNO DE ANCLAJE ARTICULACIÓN PERFILES C TENSOR 30 MM @ 1 m \W5.25895; SECCIÓN CONSTRUCTIVA \W8.90416; esc 1:10 Calle Gualaquiza N -1.50 N -1.20 N -3.50 N -1.20 N -2.00 N -2.00 Psicología Pediatría 2 - 3 años Estimulación Temprana Estimulación Temprana 2 Rampa 5% Rampa 5% Rampa 5% N +-0.00 N +0.10 N -0.44 N -0.98 N -1.50 SECCIÓN CONSTRUCTIVA ANDREA N. RUBIO J. N - 3.50 N - 0.27 \W2.49227; Tierra Abonada Suelo Natural Perno tipo Hiltty 1.2" \W2.29897; Placa de Anclaje Armadura inferior zapata Hormigón de Limpieza Perno tipo Hiltty 1.2" \W2.30928; Mortero de Nivelación \W2.39691; Columna Metálica A-36 e=6mm @6.00m Sección Constructiva esc 1:10 \W2.29897; Piedra Bola \W2.28866; Hormigón Simple \W2.57732; Armadura longitudinal 12mm \W2.29897; Dintel de 19 \W2.39691; Cercos 6mm @15 cm \W2.29897; Perfil Viga Tipo I Soldadura (Cruce de Vigas) \W2.41237; Soldadura cruce vigas + columna \W2.30928; Muro Hormigón Armado f'c=210 kg/m2 \W2.49227; Tornillo cabeza hexagonal \W2.41237; Soporte metálico para acrílico e=6mm \W2.29897; Plancha de Acrílico 1,20 m * 1,00 m \W2.29381; Refuerzo 12mm @15 cm \W2.29897; Plancha de Acrílico 1,20 m * 1,00 m \W2.29897; Deck metálico \W2.29897; Pernos 3 * 16 * 3/4 \W2.18557; 15 mm @40 cm \W2.30928; Malla Electrosoldada 15mm @15 cm \W2.31443; Losa de Hormigón Visto f'c=180 kg/m2

Language	Spanish
Drawing Type	Section
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials	Concrete, Glass, Wood
Measurement Units
Footprint Area
Building Features	Deck / Patio
Tags	anchored, autocad, béton armé, concrete, constructive, cover, curves, deck, DWG, formwork, nursery, ramp, ramps, reinforced concrete, schalung, section, stahlbeton, supporting, tensioners, wall
