Structural panel Covintec (800-76)

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

finished, plot of the, weight without stucco, finished wall thickness, welding points, amount of steel, polystyrene density, polystyrene thickness, thickness between, high standard, request heights, width, mts., cm., cm., structural panel, mts., cm., mts., plot of the, weight without stucco, finished wall thickness, welding points, amount of steel, polystyrene density, polystyrene thickness, thickness between, high standard, request heights, width, mts., cm., cm., master panel covintec, mts., cm., mts.

Raw text data extracted from CAD file:

-6.545707210229352 76cm. -6.545707210229352 -6.545707210229352 \A1;10-13cm. TERMINADO \A1;5cm. \A1;10cm. Trama de la malla(Alto x Largo) Peso sin estuco Espesor muro terminado Puntos de soldadura x m Cuantía de acero Densidad poliestireno Espesor poliestireno Espesor (Separación entre mallas) Alto standard Alturas a pedido Ancho 10.00 kg/m 2.04 a 3.65 mts. 2 11 a 13 cm. 2 3.7 kg/m 1.680 3.12 kg/m 5 x 5 cm. PANEL ESTRUCTURAL (1100-76) 1.22 mts. 7.60 cm. 5.50 cm. 2.44 mts. 3 Trama de la malla(Alto x Largo) Peso sin estuco Espesor muro terminado Puntos de soldadura x m Cuantía de acero Densidad poliestireno Espesor poliestireno Espesor (Separación entre mallas) Alto standard Alturas a pedido Ancho 10.00 kg/m 2.04 a 3.65 mts. 2 10 a 13 cm. 2 2.67 kg/m 880 2.12 kg/m 5 x 10 cm. PANEL MASTER COVINTEC (800 - 76) 1.22 mts. 7.60 cm. 5.50 cm. 2.44 mts. 3 2
